Ardex Flashing Tape 100mm x 4.7m
The butyl detailing tape for corners, pipes and outlets under ARDEX Weldtec sheet membranes.
ARDEX Flashing Tape is a black butyl rubber mastic tape on a polyethylene backing. It is the detailing tape for the ARDEX Weldtec membrane system. Cut it to size, bond it to the prepared substrate with ARDEX WA 98 Adhesive, then glue or heat-weld the Weldtec membrane over it.
What it's for
- All external corners before the Weldtec membrane goes down
- Pipe penetrations
- Drainage waste outlets
Why waterproofers buy it
- Extremely malleable, so it works into tight corners and around pipes
- Creates a continuous, watertight detail in critical areas
- Weldtec membrane glues or heat-welds straight to it
- Non-hazardous chemical, non-dangerous goods
Specs
100mm wide roll. Butyl rubber mastic on a polyethylene backing with a release layer. Bond with ARDEX WA 98 Adhesive. ARDEX publish no technical data sheet for this tape, only a safety data sheet.
Butyl rubber mastic tape on a polyethylene backing
For external corners, pipe penetrations and drainage waste outlets
ARDEX Weldtec membrane glues or heat-welds to it for a seamless detail
7-Day Money BackGuarantee
Fast DispatchNext Business Day
Expert Advice(02) 8021 3517
Secure CheckoutSSL EncryptedPickup available at The Waterproofing Shop
Usually ready in 24 hours
Ardex Flashing Tape 100mm x 4.7m
The Waterproofing Shop
22/872 Canterbury Road
Roselands NSW 2196
Australia
Product Details
How to Use
Technical Specifications
Product Files
Frequently bought together
-
-
-
FORSPEC Spike Shoes $100.00 -
Technical overview
Key applications
- External corners prior to ARDEX Weldtec membrane installation
- Pipe penetrations prior to ARDEX Weldtec membrane installation
- Drainage waste outlets prior to ARDEX Weldtec membrane installation
- Detailing critical areas within an ARDEX Weldtec membrane system
ARDEX publish no technical data sheet for this product, so there is no published application temperature, service temperature, substrate list, shelf life or performance data for it. It is a detailing tape used within an ARDEX Weldtec membrane system: it is cut to size and adhered to the prepared substrate with ARDEX WA 98 Adhesive, and the ARDEX Weldtec membrane is then glued and or heat-welded to it. The safety data sheet classifies it as a non-hazardous chemical and non-dangerous good, but still directs that it be used in a well-ventilated area, that contact with incompatible materials be avoided, and that it be stored in a cool, dry, well-ventilated area away from oxidising agents and strong acids and bases.
Calculate your coverage
You will need:
Ardex Flashing Tape 100mm x 4.7m
1kg Kit
Total coverage: 0 m²
This is an estimate only. Add 10% for wastage.
Technical Specifications
| Product Type | Butyl rubber joining and flashing mastic tape |
| Appearance | Slightly black tacky solid in a roll form with polyethylene backing |
| Backing | Polyethylene backing with release surface layer |
| Water Solubility | Insoluble in water |
| Size | 100mm wide x 5m long (size published by ARDEX) |
| ARDEX Product Code | 10397 |
| Uses | All external corners, pipe penetrations and drainage waste outlets prior to ARDEX Weldtec membrane installation |
| Bonding | Cut to size and adhered to the prepared substrate with ARDEX WA 98 Adhesive |
| Membrane Connection | ARDEX Weldtec membrane is glued and or heat-welded to the tape |
| Hazard Classification | Non-Hazardous Chemical, Non-Dangerous Goods |
| Storage | Store in a cool, dry, well-ventilated area, away from incompatible materials |
| Storage Incompatibility | Oxidising agents, strong acids and bases |
| ARDEX publish no technical data sheet for this product. The figures above come from the ARDEX safety data sheet and the ARDEX product page. | |
Frequently asked questions
-
Where is Flashing Tape used?
CompatibilityFlashing Tape is a 100mm self-adhesive tape used for corners, junctions, pipe penetrations, and detail areas under ARDEX liquid membranes. It provides reinforcement at the most vulnerable points of a waterproofing system.
-
Do I need a primer before applying Flashing Tape?
InstallationYes. The substrate must be primed with Multiprime or P51 and allowed to dry before applying the Flashing Tape. This ensures permanent adhesion to the substrate.
-
Is Flashing Tape compatible with all ARDEX membranes?
PerformanceYes. Flashing Tape is designed to be overcoated with any ARDEX liquid waterproofing membrane (WPM 002, 155, 310, 750, 1000 etc.) as part of an integrated system.
-
How is Flashing Tape applied?
InstallationApply Flashing Tape to primed substrates with firm hand pressure, eliminating air bubbles. Apply before the first coat of membrane, then overcoat with two membrane coats.
-
What size is the tape?
CompatibilityFlashing Tape comes as a 100mm wide by 4.7m long self-adhesive roll, sized for corner and junction detail work.
