Forspec ACTFLEX 5000 Sanded Waterproof Membrane roll measuring 1m x 20m, a self-adhesive waterproof membrane with a sanded surface for below-ground and structural waterproofing applications.

ACTFLEX 5000 (Sanded) 1m x 20m

Name: ACTFLEX 5000 (Sanded) 1m x 20m
Brand: Forspec Protective Coatings
SKU: AACT801
Price: 770.00 AUD
Availability: InStock

$770.00

or 4 interest-free payments with

Pre-applied butyl sheet with a reactive sand face. The slab bonds to it, so water cannot track underneath.

ACTFLEX 5000S is a self-adhesive butyl rubber sheet for below-ground and structural work where the slab must bond to the membrane, not just sit on it. The reactive sand top layer fires on contact with fresh concrete or heated mortar and forms a chemical bond of about 1.0 to 1.5 MPa shear. 1 m x 20 m roll, laid sand face up.

Where to use it

Basement walls and floors, raft slabs
Retaining walls and foundation walls
Lift pits and below-ground tanks
Tunnels and podium slabs
Under concrete toppings and screeds that must bond to the membrane

Why waterproofers buy it

Reactive sand fuses the membrane to the poured topping slab
Stops lateral water migration between membrane and slab. Impermeable at 0.8 MPa across a 35 mm hydraulic gradient
Impermeable for 120 minutes at 0.6 MPa. Typical R&D values
Peel and stick. No torching, no site adhesives. Vertical and horizontal
Flexible to minus 25°C, no cracking
10 year Forspec product warranty

Coverage

1 m x 20 m roll, approx. 30 kg. 75 mm side and end laps. Take-off is measured area plus upturns, plus 20% for laps and wastage.

Not for

Exposed use (cover it with the topping or backfill, it is not UV stable), exposed trafficable surfaces, anything beyond minimal negative pressure (check the groundwater with the engineer), structural crack repair, frosted substrates, standing water or sharp projections. Keep the sand face clean and dry until the pour, and never prime or coat it.

Reactive sand top layer chemically fuses the membrane to the poured topping slab

Stops lateral water migration between membrane and slab at 0.8 MPa across a 35mm gradient

Self-adhesive butyl rubber with no torching and no site adhesives

Quantity: 1

7-Day Money BackGuarantee

Fast DispatchNext Business Day

Expert Advice(02) 8021 3517

Secure CheckoutSSL Encrypted

Get it — —

Pickup available at The Waterproofing Shop

Usually ready in 24 hours

ACTFLEX 5000 (Sanded) 1m x 20m

The Waterproofing Shop

Pickup available, usually ready in 24 hours

22/872 Canterbury Road
Roselands NSW 2196
Australia

+61280213517

How to Use

Peel and stick with the reactive sand face upwards, then pressure roll the full bonded area and every lapConfirm the substrate is structurally sound, clean, dry and free of laitance, dust, oil, grease, curing compounds, release agents and all bond-inhibiting contaminants
Confirm concrete is fully cured, a minimum of 28 days, and free of standing water and frost
Remove all high points, fins, sharp projections and protruding fixings, and grind back honeycombing
Reinstate blowholes, voids, spalls and defects with FORBUILD 100 or FORCRETE 100, finished flush and cured
Form all internal corners and floor-to-wall junctions as a smooth cove or fillet before the membrane is laid
Confirm the substrate falls and drainage are set out and correct before covering
Vacuum the area thoroughly immediately before installation
Confirm the surface is dry and free of standing water
Set out the sheet layout with the reactive sand face UPWARDS, ready to receive the topping pour
Detail internal corners, floor-to-wall junctions and penetrations with a separate detail strip and roller it into both planes
Position and align the sheet dry, then peel the release liner progressively and bed the membrane from one edge to exclude air
Consolidate the full bonded area with a weighted or hand pressure roller
Overlap all side and end laps by a minimum of 75 mm and roller every lap firmly along its full length
Protect the installed membrane from site traffic, mud, ponded water and contamination until the pour
Inspect every lap, corner and penetration for lifting, fishmouths, wrinkles and trapped air, and cut out and re-detail any defect before the pour
Obtain pre-pour release from the site inspection before concrete is placed
Place the topping concrete or heated mortar directly onto the reactive sand surface - the bond forms on contact

Technical Specifications

Membrane Classification: Pre-applied self-adhesive butyl rubber sheet membrane
Chemical Base: Self-adhesive butyl rubber with a thermal-chemical reactive sand top layer
Bond Interface to Topping Slab: Shear stress capacity approx. 1.0-1.5 MPa*
Tensile Strength: 600 N/50mm minimum*
Elongation at Break: 150% minimum*
Stretching Behaviour: No separation between adhesive layer and polymer film*
Nail Shank Tear Strength: 300 N minimum*
Puncture Resistance: 200 N minimum*
Impact Resistance: 0.5 kg.m, no seepage*
Resistance to Static Loading: 20 kg, no seepage*
Heat Resistance (80C, 2 hours): Slippage 2mm or less*
Low Temperature Flexibility: -25C, no cracking*
Oil Permeability: 2 sheets or less*
Impermeability: Impermeable for 120 minutes at 0.6 MPa*
Resistance to Water Movement Between Layers: Impermeable for 120 minutes at 0.8 MPa across a 35mm hydraulic gradient*
Peel Strength, Membrane to Membrane at Overlap: 1.5 N/mm minimum untreated; 1.0 N/mm minimum after immersion, contamination, UV or heat treatment*
Peel Strength to Concrete, Bottom Surface: 1.5 N/mm minimum untreated; 1.0 N/mm minimum after heat treatment*
Heat Ageing (80C, 168 hours): Tension retention 90% minimum; elongation retention 80% minimum; flexible at -23C, no cracking*
Dimensional Change Rate: Plus or minus 1.5%*
Minimum Overlap: 75mm side and end laps*
Roll Size: 1m x 20m (20m2 gross per roll)
Roll Weight: Approx. 30 kg
Adhesion Development: Immediate on pressure rolling - no cure period*
Chemical Bond Development: On contact with fresh concrete or heated mortar
Shelf Life: 24 months, unopened, stored dry and shaded*
* Typical Forspec R&D characteristic values - no accredited test reports exist for this product

Product Files

ACTFLEX 5000 (Sanded) 1m x 20m

$770.00

Frequently bought together

This item

ACTFLEX 5000 (Sanded) 1m x 20m $770.00
Add

125mm Arrow Cup Grinding Disc $100.00
Add

600mm True Blue Digital Level - Empire $175.00
Add

ACTFLEX 101 UV Stable Trafficable Membrane $250.00

System Build-Up Guide

Correct application makes all the difference.

View All Details

Pool System Build-Up

1 Concrete Substrate
2 Crack Repair (if required)
3 ACTFLEX FLEXPLUS
4 ACTFLEX HYDROPLUG
5 ACTFLEX AT MESH
6 ACTFLEX 988 CWP (2 Coats)
7 Tile Adhesive
8 Pool Finish

Retaining Wall System Build-Up

1 Concrete Substrate
2 Crack Repair (if required)
3 ACTFLEX MS PRO
4 ACTFLEX AT MESH
5 ACTFLEX 988 CWP (2 Coats)
6 Protection Board (Optional)
7 Drainage System
8 Backfill

Tank System Build-Up

1 Concrete Substrate
2 Crack Repair (if required)
3 ACTFLEX FLEXPLUS
4 ACTFLEX AT MESH
5 ACTFLEX 988 WMP (2 Coats)
6 Protective Coating (Optional)
7 Water

Technical overview

ACTFLEX 5000S is a pre-applied self-adhesive butyl rubber sheet membrane for critical below-ground and structural waterproofing where the topping slab must bond to the membrane rather than merely rest on it. Its top layer of thermal-chemical reactive sand activates on contact with fresh concrete or heated mortar and forms a chemical bond between the topping and the membrane, with a bond interface shear stress capacity of approximately 1.0 to 1.5 MPa. It is impermeable for 120 minutes at 0.6 MPa and resists inter-layer water movement at 0.8 MPa across a 35mm gradient. Designed and manufactured to comply with AS/NZS 4858 and AS 4654.1, verification testing scheduled. No accredited certificate is currently held on file and all performance values are published as typical R&D characteristic values.

Key applications

Basement walls and floors
Retaining walls and foundation walls
Lift pits and below-ground tanks
Tunnels and podium slabs
Raft slabs
Pre-applied membrane installation on slabs and substrates with minimal negative pressure
Under concrete toppings and screeds where chemical adhesion to the membrane is required
Bonded topping slabs requiring chemical integration with the waterproofing layer
External wet areas, non-exposed

Surface suitability

Structural slabs, precast panels and blockwork
Concrete (structurally sound, minimum 28 days cured, free of standing water and frost)
Concrete (blowholes, voids, spalls and defects reinstated with FORBUILD 100 or FORCRETE 100, finished flush and cured)
Vertical and horizontal surfaces
Substrates with minimal negative pressure only, confirmed with the project engineer

Non-exposed applications only - ACTFLEX 5000S must be covered by the topping slab, protection, backfill or finish and must not be left permanently exposed to UV. Not for use as an exposed trafficable surface. Pre-applied use is limited to substrates with minimal negative pressure; confirm the groundwater regime and negative head with the project engineer before specifying. The reactive sand surface must be kept clean and dry before the pour - contamination, ponded water, mud or trafficking will prevent the chemical bond from forming, and the surface must never be primed, coated or covered with any product before the topping is poured. Not a substitute for structural crack repair; active and structural cracks must be treated before the membrane is laid. Do not install over frosted substrates, standing water, or substrates with sharp projections. Laps must be rolled and inspected - an unrolled lap is not a sealed lap.

Technical Specifications

Membrane Classification	Pre-applied self-adhesive butyl rubber sheet membrane
Chemical Base	Self-adhesive butyl rubber with a thermal-chemical reactive sand top layer
Bond Interface to Topping Slab	Shear stress capacity approx. 1.0-1.5 MPa*
Tensile Strength	600 N/50mm minimum*
Elongation at Break	150% minimum*
Stretching Behaviour	No separation between adhesive layer and polymer film*
Nail Shank Tear Strength	300 N minimum*
Puncture Resistance	200 N minimum*
Impact Resistance	0.5 kg.m, no seepage*
Resistance to Static Loading	20 kg, no seepage*
Heat Resistance (80C, 2 hours)	Slippage 2mm or less*
Low Temperature Flexibility	-25C, no cracking*
Oil Permeability	2 sheets or less*
Impermeability	Impermeable for 120 minutes at 0.6 MPa*
Resistance to Water Movement Between Layers	Impermeable for 120 minutes at 0.8 MPa across a 35mm hydraulic gradient*
Peel Strength, Membrane to Membrane at Overlap	1.5 N/mm minimum untreated; 1.0 N/mm minimum after immersion, contamination, UV or heat treatment*
Peel Strength to Concrete, Bottom Surface	1.5 N/mm minimum untreated; 1.0 N/mm minimum after heat treatment*
Heat Ageing (80C, 168 hours)	Tension retention 90% minimum; elongation retention 80% minimum; flexible at -23C, no cracking*
Dimensional Change Rate	Plus or minus 1.5%*
Minimum Overlap	75mm side and end laps*
Roll Size	1m x 20m (20m2 gross per roll)
Roll Weight	Approx. 30 kg
Adhesion Development	Immediate on pressure rolling - no cure period*
Chemical Bond Development	On contact with fresh concrete or heated mortar
Shelf Life	24 months, unopened, stored dry and shaded*
* Typical Forspec R&D characteristic values - no accredited test reports exist for this product
