ACTFLEX Crystal Coat 30L Solvent Free 2 Part Epoxy
or 4 interest-free payments with
100% solids epoxy floor coating for heavy traffic. Clear or coloured, 0.2 mm to 1 mm in one product, 30 L kit.
ACTFLEX CRYSTAL COAT is a two-part, solvent-free cycloaliphatic epoxy floor coating for heavy-duty, decorative and commercial floors. It goes on concrete, metal and timber from 0.2 mm to 1 mm. Fill it with sand for a repair mortar, add coloured oxides for a non-slip floor, or add FORSPEC Metallic Pigments for a decorative finish.
Where to use it
- Warehouses, factories, retail stores and showrooms
- Hospitals, schools, labs and food processing areas
- Car parks, ramps and structural protection
- Prime first: ACTFLEX 700 PU PRIMER below 4.5% substrate moisture, or two coats of ACTFLEX EP 250 above 4.5%
Why waterproofers buy it
- 100% solids and solvent free. High build with minimal VOCs
- Withstands heavy traffic and mechanical wear. Shore D 60, abrasion resistance 98 (ASTM C501-84)
- Low viscosity. Pour, spread with a notched squeegee, back-roll
- Clear or coloured to AS2700
- Recoat 6 to 24 hours, light foot traffic at 24 hours, full cure at 7 days
- 30 L kit, 20 L Part A plus 10 L Part B, mixed 2 to 1
Coverage
30 L kit: 101 m² at 0.3 mm DFT, 51 m² at 0.6 mm, 33 m² at 1.0 mm. Primer is extra.
Not for
External work without a UV-resistant topcoat (not UV stable), application below 10°C, water contact in the first 24 hours, flexible substrates or areas with excessive movement. Pot life is about 30 minutes. Shelf life 9 months unopened.
All times at 25°C.
100% solids and solvent-free, a high build durable finish with minimal VOCs
Applies from 0.2mm to 1mm on concrete, metal and timber
Fill with sand or oxides for non-slip, or FORSPEC metallic pigments for decorative floors
7-Day Money BackGuarantee
Fast DispatchNext Business Day
Expert Advice(02) 8021 3517
Secure CheckoutSSL Encrypted
Get it
—
—
Pickup currently unavailable at The Waterproofing Shop
ACTFLEX Crystal Coat 30L Solvent Free 2 Part Epoxy
The Waterproofing Shop
22/872 Canterbury Road
Roselands NSW 2196
Australia
Product Details
How to Use
Technical Specifications
ACTFLEX Crystal Coat 30L Solvent Free 2 Part Epoxy
Sale price$963.00
Frequently bought together
System Build-Up Guide
Correct application makes all the difference.
Retaining Wall System Build-Up
- 1 Concrete Substrate
- 2 Crack Repair (if required)
- 3 ACTFLEX MS PRO
- 4 ACTFLEX AT MESH
- 5 ACTFLEX 988 CWP (2 Coats)
- 6 Protection Board (Optional)
- 7 Drainage System
- 8 Backfill
Tank System Build-Up
- 1 Concrete Substrate
- 2 Crack Repair (if required)
- 3 ACTFLEX FLEXPLUS
- 4 ACTFLEX AT MESH
- 5 ACTFLEX 988 WMP (2 Coats)
- 6 Protective Coating (Optional)
- 7 Water
Technical overview
Key applications
- Industrial and commercial flooring: warehouses, factories, retail stores and showrooms
- Institutional spaces: hospitals, schools, labs and pharmaceutical facilities
- Food and beverage industry: kitchens, breweries and food processing areas
- Construction and civil projects: car parks, ramps and structural protection
- Metal and timber surfaces: durable coating for heavy-use areas
- Non-slip flooring: enhanced grip when combined with fillers
- Decorative metallic flooring with FORSPEC Metallic Pigments and Paste
Surface suitability
- Concrete (mechanically ground or shot blasted to a minimum CSP 2-3, moisture content below 4%, no acid etching)
- Metal (cleaned, degreased and abraded, then primed with an appropriate ACTFLEX primer)
- Timber (cleaned, degreased and abraded, then primed with an appropriate ACTFLEX primer)
Not UV stable, so external applications require a UV-resistant topcoat. Not suitable for application below 10C as curing will be significantly slowed; the application temperature range is 10-30C. Moisture sensitive during curing, so avoid water exposure within the first 24 hours. Substrate moisture content must be checked and a moisture barrier primer, ACTFLEX EP 250 in two coats, applied where it is above 4.5%. Strict mixing ratios must be followed to prevent improper curing and performance issues. Must be mixed and applied within its pot life. Recoating beyond 24 hours requires light mechanical sanding for adhesion. Not recommended for flexible substrates or areas with excessive substrate movement. Poor adhesion may occur on contaminated or improperly prepared substrates. Hazardous, may cause skin and eye irritation, and uncured product is combustible, so keep all sources of ignition away.
Calculate your coverage
You will need:
ACTFLEX Crystal Coat 30L Solvent Free 2 Part Epoxy
30Lr kit
0 Kits
Total coverage: 0 m²
This is an estimate only. Add 10% for wastage.
Technical Specifications
| Product Type | Two-component high build, 100% solids solvent-free cycloaliphatic epoxy floor coating |
| Chemical Base | Low viscosity cycloaliphatic epoxy resin |
| Colour | Clear or coloured (AS2700) |
| Mix Ratio | 2:1 |
| Solids Content | 100% |
| Packaging | 30L (20L Part A, 10L Part B) |
| Application Thickness Range | 0.2mm to 1mm |
| Shore Hardness A | 95* |
| Shore Hardness D | 60* |
| Elongation at Break | Less than 100%* |
| Abrasion Resistance | 98 (ASTM C501-84, H18 wheel @ 1,000rpm with 1,000g weight) |
| Fatigue Cracking | Pass* |
| Flash Point | 97C* |
| Pot Life | 30 minutes working time @ 25C; the properties table separately states 45 minutes |
| Recoat Time | 6-24 hours between coats @ 25C; the properties table separately states 4 hours @ 25C, 50% RH |
| Touch Dry | 6-8 hours @ 25C, 50% RH |
| Hard Through Time | 4 hours @ 25C, 50% RH* |
| Light Foot Traffic | 24 hours |
| Full Cure | 7 days for heavy traffic and chemical resistance |
| Application Temperature | 10-30C |
| Coverage at 0.3mm DFT | 3.3 m2/L, 101 m2 per 30L kit |
| Coverage at 0.6mm DFT | 1.7 m2/L, 51 m2 per 30L kit |
| Coverage at 1.0mm DFT | 1.1 m2/L, 33 m2 per 30L kit |
| Substrate Moisture | Below 4%; above 4.5% requires ACTFLEX EP 250 as a two-coat moisture barrier |
| Surface Profile | Minimum CSP 2-3, mechanically ground or shot blasted, no acid etching |
| Shelf Life | 9 months in the original unopened containers stored at 10-22C |
| Hazard Classification | Hazardous, may cause skin and eye irritation; uncured product is combustible |
| * Manufacturer published values. ASTM C501-84 is cited for abrasion resistance only | |
Real Projects. Real Results.
-
Before
After
Pool Renovation
Gold Coast, QLD
-
Before
After
Below Ground Retaining Wall
Sydney, NSW
-
Before
After
Concrete Water Tank
Perth, WA
-
Before
After
Commercial Podium
Melbourne, VIC
-
Before After
Swimming Pool Construction
Brisbane, QLD
Watch the install
Step-by-step from prep to top coat. Filmed on the tools, not in a studio.
The Waterproofing Shop?
We supply premium waterproofing products backed by expert advice, fast service and real-world experience.
100% AustralianOwned & Operated
30+ Years in theWaterproofing Industry
Thousands of Productsin Stock
Fast ShippingAustralia Wide
Expert TechnicalSupport
Frequently asked questions
-
What is ACTFLEX Crystal Coat used for?
CompatibilityCrystal Coat is a 100% solids two-part cycloaliphatic epoxy used for industrial flooring, decorative flake floor systems, high-traffic floors, and as an epoxy screed (1-90mm thickness). Suitable for primed concrete substrates.
-
What's the compressive strength?
PerformanceCrystal Coat achieves up to 60 MPa compressive strength - industrial-grade performance suitable for forklift traffic, plant rooms, and heavy commercial environments. 100% solids means zero shrinkage and full chemical resistance.
-
What's the coverage at different thicknesses?
InstallationCoverage is 3.3 m² per litre at 0.3mm DFT, 1.7 m² per litre at 0.6mm, or 1.1 m² per litre at 1.0mm. Touch-dry in 48 hours at 25°C/50% RH, recoat in 6-24 hours, handling in 48 hours, full waterproofing in 7 days.
-
Is it solvent-free?
CompatibilityYes. Crystal Coat is 100% solids solvent-free epoxy with minimal colour change after cure. Available in clear or coloured finishes for decorative or industrial applications. Apply at 10-30°C ambient.
-
Can I broadcast FLAKE X into it?
PerformanceYes - Crystal Coat is the standard basecoat for the FLAKE X decorative flake floor system. Broadcast FLAKE X into the wet epoxy, then topcoat with Ultra Shield polyaspartic for the full decorative flake floor system.
