Neoprene flange. Holds the flood test water, then stays in as the permanent puddle flange.
The ACTNOW 100mm Rubber Puddle Flange is a flexible neoprene rubber flange that seals a 100mm PVC drainage outlet to the waterproofing membrane. Install it with the base intact and it holds the flood test water. Slice the base open when the test passes and it stays in as the puddle flange.
What it's for
Why waterproofers buy it
Specs
Black neoprene. 150mm wide, 35mm deep, 100mm centre opening. Recess it flush with the slab.
Not for
Anything other than concrete, or concrete under 28 days old. Keep it clear of bond breakers and wall junctions. Slicing the base is irreversible, so pass the test first.
Neoprene flexible rubber flanges that create a watertight connection between 100mm PVC drainage outlets and your waterproofing membrane. For internal and external wet areas on concrete, and backed for life.
Not sure? Compare standard vs flood test
or 4 interest-free payments of $3.00 with AfterPay ex GST $10.90
Prep and sealing gear that goes in alongside the flange.
A $12 part sits under a bathroom for the life of the building. Actnow warrants it for that long, which tells you what they think of the rubber, and takes the cheapest possible failure point off your risk list.
The flexible rubber body forgives an out-of-square riser and moves with the slab instead of fighting it. Membrane bonds cleanly to the flat rubber collar, and there is no rigid lip to crack under screed.
The test version comes with the bottom blocked off from the factory. Fill the area, hold the test, then make a small incision to release the water. No balloon, no plug, no extra hire.
Designed specifically for 100mm drainage outlets and floor wastes in concrete substrates, for both internal and external wet areas. Australian designed, Design Registration 201814766.
Same rubber, same install. The only difference is what happens at the bottom of the flange.
The everyday flange. Open outlet, straight through to the drain. Flood test with a balloon or plug when you need to.
The bottom is blocked off from the factory. Fill the area, hold your test, then cut a small incision to release the water.
Running the standard flange? Add a flood test balloon so you can still test the area before handover.
Four steps, no extra equipment, no hiring a plug.
Seat the test flange on the 100mm outlet and bond the membrane to the rubber collar as normal.
The blocked bottom holds the water, no balloon, no plug, nothing to hire or inflate.
Leave the test to stand and check the area below for any sign of water tracking through.
A small incision in the blocked base releases the water, and the flange stays in as the permanent detail.
The full install on a concrete slab, start to finish.
Australian designed neoprene rubber flanges for concrete substrates, backed by a lifetime warranty.
Both versions side by side, so you can check the fit before you order.
They are the same rubber flange with the same installation method. The flood test version has the bottom blocked off from the factory so it holds water for a flood test without a balloon. Once the test passes, you cut a small incision in the base to drain it and the flange stays in permanently.
Not with the flood test flange, that is the point of it. With the standard flange you will need a balloon or plug to hold water for the test. Plenty of trade customers keep balloons on hand anyway for other outlets and pipe sizes on the same job.
The neoprene body flexes, so it forgives a riser that is slightly out of square and moves with the slab rather than fighting it. There is no rigid lip to crack under screed, and the membrane bonds cleanly to the flat rubber collar.
Yes. It is designed for internal and external wet areas on concrete substrates, in residential and commercial work.
The flange is warranted for the life of the installation rather than a fixed term. Keep your receipt on file with the job documentation.
Both versions ship 100 per box. Pricing is shown live in the buy box above, so it always reflects any promotion running at the time.
It is designed specifically for concrete substrates. For FC sheeting and timber floors, talk to us on (02) 8021 3517 about the right detail for your build-up.
Lifetime warranty, dispatched next business day. Buy by the box and never hold up a job.
