What's in the Garage Flake Flooring Starter Kit?

The Garage Flake Flooring Kit contains a complete decorative flake floor system: epoxy primer/basecoat, ACTFLEX Crystal Coat (or similar epoxy base), FLAKE X decorative flake, ACTFLEX Ultra Shield polyaspartic topcoat, and application tools (squeegee, mixing paddle, spike shoes).

What surface area does it cover?

Sized for a standard single-car or double-car garage floor (approx 15-30 m² depending on the kit variant). Refer to the kit description for exact coverage and additional material requirements for larger spaces.

Can I apply this myself?

Yes - the kit is designed for DIY application by competent applicators willing to follow the system instructions carefully. The biggest pitfalls are surface prep (must be ground/etched) and timing the flake broadcast in the wet epoxy window.

What's the prep required for an existing concrete garage?

Critical prep: grind or acid-etch the concrete to open the surface profile, vacuum thoroughly, fill any cracks with epoxy paste, then prime. Skipping prep is the #1 cause of garage floor failures.

How long does it take from start to finish?

Plan 3 days minimum: Day 1 prep and prime, Day 2 epoxy basecoat with flake broadcast, Day 3 topcoat. Light foot traffic in 24 hours, vehicle traffic in 7 days for full cure.

Garage Flake Flooring Starter Kit - EOFY Trade Deal

Be the first to review

Starter Kit - Garage Flake Flooring

Name: Starter Kit - Garage Flake Flooring
Brand: Forspec Protective Coatings
SKU: SSTF643
Price: 1560.00 AUD
Availability: InStock

$1,560.00

$1,732.90

LIMITED TIME DEAL

SAVE $172.90

or 4 interest-free payments with

Polyaspartic flake floor for the garage. Hard through in 3.5 hours, drive on it after 48.

ACTFLEX ULTRA SHIELD is a two-component polyaspartic floor coating at 90% solids, applied straight onto prepared concrete. In this kit it is the base coat you broadcast the flake into and the clear lock coat over the top. ACTFLEX EP250 epoxy primer handles damp slabs. The coating is polyaspartic, not epoxy.

What's in the kit

ACTFLEX ULTRA SHIELD, base coat
ACTFLEX ULTRA SHIELD, clear lock coat
FLAKE X decorative flake
ACTFLEX EP250 two-component waterborne epoxy primer

Where to use it

Garage floors and commercial, industrial and residential flooring
High wear and traffic prone areas, food processing floors
Decorative flake or solid colour finishes over prepared concrete

Why buy the kit

90% solids, 93 Shore A, 56 Shore D
Hard through 3.5 hours, full cure 48 hours. Coat it and hand it back inside a shift
High UV stability, resists yellowing
Bridges hairline cracks and absorbs minor substrate movement
Puncture and abrasion resistance built for vehicle traffic. No joints or laps
EP250 goes on as two coats of moisture control where the slab is over the 5% limit
10 year Forspec product warranty on ULTRA SHIELD, supply only

Coverage

ULTRA SHIELD: 6 to 8 m² per litre per coat, two coats for a flake floor. Flake systems use significantly more clear coat than a solid colour, so set flake demand on a trial area. EP250 if needed: 0.44 kg/m² per coat.

Not for

Below 10°C or above 30°C, slabs over the moisture limit without two coats of EP250, old paint or resin (strip it first), levelling or structural repair, or a slip rating as supplied (broadcast anti-slip). Mix full kits only, 30 minute pot life. Part B is a flammable liquid and dangerous goods.

All times at 25°C and 50% RH.

Polyaspartic base and clear coat at 90% solids, hard through in 3.5 hours

Flake broadcast to refusal into the wet base coat, then a clear lock coat

Elastomeric film bridges hairline cracks and absorbs minor substrate movement

Quantity: 1

7-Day Money BackGuarantee

Fast DispatchNext Business Day

Expert Advice(02) 8021 3517

Secure CheckoutSSL Encrypted

Get it — —

Pickup available at The Waterproofing Shop

Usually ready in 24 hours

Starter Kit - Garage Flake Flooring

The Waterproofing Shop

Pickup available, usually ready in 24 hours

22/872 Canterbury Road
Roselands NSW 2196
Australia

+61280213517

How to Use

Apply ACTFLEX ULTRA SHIELD by roller, brush or spray at 6-8 m2 per litre, broadcasting the flake into the wet base coat before the clear lock coatInspect the floor thoroughly and confirm it is structurally sound, clean and free of damage, checking for cracks, holes and surface imperfections
Remove all contaminants - dust, grease, oil, wax, paint and other residues - using a degreaser where required, followed by a rinse with clean water, and allow to dry fully
Where the surface carries a previous paint or resin coating, remove it completely by sanding, grinding or abrasive blasting
Repair all cracks and spalling with a FORSPEC concrete repair system such as FORBUILD 100 or FORCRETE 100, or the FORSPEC epoxy crack repair range, finished flush and cured
Mechanically prepare the substrate by diamond grinding or shot blasting to an open, sound profile and vacuum thoroughly
Confirm substrate moisture is within the limit stated in the Technical Data; where the limit is exceeded, apply ACTFLEX EP250 as a two-coat moisture-control system
Where EP250 is used, mix it 1:1 Part A to Part B by volume, apply at 0.44 kg/m2 per coat and allow a minimum of 24 hours cure at 25C and 50% RH before overcoating
Vacuum the area immediately before application
Pre-condition both ULTRA SHIELD components before mixing and mix full kits only - never part-mix
Combine the components and mix with a low-speed mechanical mixer to a uniform, streak-free blend, scraping the sides and base of the container, without whipping air into the mix
Mix only the quantity that can be placed within the 30-minute pot life
Apply the ULTRA SHIELD base coat by roller, brush or spray at 6-8 m2 per litre, working to a uniform, continuous film and maintaining a wet edge
Broadcast the flake into the wet base coat to the required density
Allow the base coat to cure, then remove all loose flake by vacuum and scrape
Apply the clear ULTRA SHIELD lock coat, within the 1-4 hour recoat window where a second coat is being applied wet on cured
Where enhanced surface friction is specified, broadcast the anti-slip aggregate into the wet coat and lock it in with a further coat
Protect the finished floor from water, contamination and traffic until hard through
Inspect the finished film for holidays, pinholes, flake shadowing and inconsistent gloss before releasing the area
Allow 48 hours full cure at 25C and 50% RH before vehicle traffic

Technical Specifications

System Type: Decorative polyaspartic flake floor system over prepared concrete
Base and Lock Coat: ACTFLEX ULTRA SHIELD, two-component elastomeric polyaspartic floor coating
ULTRA SHIELD Colour: Clear or custom colours
ULTRA SHIELD Solids Content: 90%*
ULTRA SHIELD Shore Hardness A: 93*
ULTRA SHIELD Shore Hardness D: 56*
ULTRA SHIELD Elongation at Break: Less than 100%*
ULTRA SHIELD Moisture Vapour Transmission: Pass (ASTM E96, manufacturer data)*
ULTRA SHIELD Fatigue Cracking: Pass, no fatigue cracking*
ULTRA SHIELD Flash Point: 97C*
ULTRA SHIELD Pot Life: 30 minutes at 25C, 50% RH
ULTRA SHIELD Recoat Window: 1-4 hours at 25C, 50% RH
ULTRA SHIELD Hard Through: 3.5 hours at 25C, 50% RH
ULTRA SHIELD Full Cure: 48 hours at 25C, 50% RH
ULTRA SHIELD Coverage: 6-8 m2/L per coat*
ULTRA SHIELD Consumption Per Coat: Approx. 0.13-0.17 L/m2*
ULTRA SHIELD Application Temperature: +10C to +30C
ULTRA SHIELD Packaging: 4 L, 20 L and 40 L
ULTRA SHIELD Shelf Life: 12 months, unopened, stored as specified*
Maximum Substrate Moisture: 5%*
Flake Broadcast: Flake broadcast to refusal into the wet base coat, then a clear lock coat*
Primer: ACTFLEX EP250, two-component waterborne epoxy primer, sealer and moisture-barrier coating
EP250 Mix Ratio: 1:1 Part A : Part B by volume, never by weight
EP250 Consumption: 0.44 kg/m2 per coat, approximately 2.3 m2 per kg
EP250 VOC Content: 23 g/L (ASTM D3960 / D2369, FORAY NATA 1231 Certificate P22070055)
EP250 Application Temperature: 10-26C, ambient and substrate
EP250 Cure Before Overcoating: Minimum 24 hours at 25C, 50% RH
Slip Resistance: Not rated as supplied, an anti-slip broadcast is required to achieve a designed rating
Hazard Classification: ULTRA SHIELD Part B is a flammable liquid and vapour and dangerous goods; both EP250 parts are hazardous chemicals and Part B is dangerous goods
* Typical Forspec R&D characteristic values - no accredited certificate is currently held for ACTFLEX ULTRA SHIELD

Product Files

Starter Kit - Garage Flake Flooring

$1,560.00

Frequently bought together

This item

Starter Kit - Garage Flake Flooring $1,560.00
Add

125mm Arrow Cup Grinding Disc $100.00
Add

600mm True Blue Digital Level - Empire $175.00
Add

ACTFLEX 101 UV Stable Trafficable Membrane $250.00

System Build-Up Guide

Correct application makes all the difference.

View All Details

Pool System Build-Up

1 Concrete Substrate
2 Crack Repair (if required)
3 ACTFLEX FLEXPLUS
4 ACTFLEX HYDROPLUG
5 ACTFLEX AT MESH
6 ACTFLEX 988 CWP (2 Coats)
7 Tile Adhesive
8 Pool Finish

Retaining Wall System Build-Up

1 Concrete Substrate
2 Crack Repair (if required)
3 ACTFLEX MS PRO
4 ACTFLEX AT MESH
5 ACTFLEX 988 CWP (2 Coats)
6 Protection Board (Optional)
7 Drainage System
8 Backfill

Tank System Build-Up

1 Concrete Substrate
2 Crack Repair (if required)
3 ACTFLEX FLEXPLUS
4 ACTFLEX AT MESH
5 ACTFLEX 988 WMP (2 Coats)
6 Protective Coating (Optional)
7 Water

Technical overview

This kit builds a decorative flake floor from ACTFLEX ULTRA SHIELD, a two-component elastomeric polyaspartic floor coating at 90% solids applied direct to well-prepared concrete, with ACTFLEX EP250 waterborne epoxy primer for substrates that exceed the stated moisture limit. FLAKE X is broadcast into the wet ULTRA SHIELD base coat and locked in with a clear ULTRA SHIELD coat. The coating is not rated for slip resistance as supplied. No accredited certificate is currently held on file for ACTFLEX ULTRA SHIELD and all its performance values are published as typical R&D characteristic values. EP250 carries a certified VOC content of 23 g/L.

Key applications

Garage floors and commercial, industrial and residential flooring
Decorative flake or solid-colour floor finishes
Direct-applied protective and decorative floor coating over prepared concrete
High-wear and traffic-prone environments
Flooring within food processing plants
Areas requiring enhanced surface friction, with the specified anti-slip broadcast

Surface suitability

Concrete (structurally sound, clean and free of damage, mechanically prepared by diamond grinding or shot blasting to an open, sound profile and vacuumed)
Concrete with all previous paint and resin coatings completely removed
Concrete with all cracks and spalling repaired with FORBUILD 100, FORCRETE 100 or the FORSPEC epoxy crack repair range, finished flush and cured
Concrete exceeding the stated moisture limit (apply ACTFLEX EP250 as a two-coat moisture-control system first)

Two-component products - mix full kits only and observe the 30-minute ULTRA SHIELD pot life; do not part-mix and never re-temper. Do not apply ULTRA SHIELD below 10C or above 30C, and apply EP250 only between 10C and 26C ambient and substrate. Not slip-resistant as supplied - an anti-slip broadcast is required to achieve a designed slip rating. Do not apply over substrates exceeding the stated moisture limit - apply ACTFLEX EP250 as a two-coat moisture-control system where the limit is exceeded. All previous paint and resin coatings must be completely removed before application. Not a structural repair product - cracks and spalling must be reinstated before coating. It bridges hairline cracks only and does not accommodate designed movement joints, which must be carried through the coating. Not a levelling product - the finished surface follows the prepared substrate profile. EP250 is not UV resistant and must be protected from direct ultraviolet exposure. Do not dilute ULTRA SHIELD unless approved in writing by an authorised FORSPEC representative. ULTRA SHIELD Part B is a flammable liquid and vapour classified as dangerous goods, is harmful if inhaled and may cause allergy or asthma symptoms or breathing difficulties if inhaled; both EP250 parts are hazardous chemicals. Read every Safety Data Sheet before use.

Technical Specifications

System Type	Decorative polyaspartic flake floor system over prepared concrete
Base and Lock Coat	ACTFLEX ULTRA SHIELD, two-component elastomeric polyaspartic floor coating
ULTRA SHIELD Colour	Clear or custom colours
ULTRA SHIELD Solids Content	90%*
ULTRA SHIELD Shore Hardness A	93*
ULTRA SHIELD Shore Hardness D	56*
ULTRA SHIELD Elongation at Break	Less than 100%*
ULTRA SHIELD Moisture Vapour Transmission	Pass (ASTM E96, manufacturer data)*
ULTRA SHIELD Fatigue Cracking	Pass, no fatigue cracking*
ULTRA SHIELD Flash Point	97C*
ULTRA SHIELD Pot Life	30 minutes at 25C, 50% RH
ULTRA SHIELD Recoat Window	1-4 hours at 25C, 50% RH
ULTRA SHIELD Hard Through	3.5 hours at 25C, 50% RH
ULTRA SHIELD Full Cure	48 hours at 25C, 50% RH
ULTRA SHIELD Coverage	6-8 m2/L per coat*
ULTRA SHIELD Consumption Per Coat	Approx. 0.13-0.17 L/m2*
ULTRA SHIELD Application Temperature	+10C to +30C
ULTRA SHIELD Packaging	4 L, 20 L and 40 L
ULTRA SHIELD Shelf Life	12 months, unopened, stored as specified*
Maximum Substrate Moisture	5%*
Flake Broadcast	Flake broadcast to refusal into the wet base coat, then a clear lock coat*
Primer	ACTFLEX EP250, two-component waterborne epoxy primer, sealer and moisture-barrier coating
EP250 Mix Ratio	1:1 Part A : Part B by volume, never by weight
EP250 Consumption	0.44 kg/m2 per coat, approximately 2.3 m2 per kg
EP250 VOC Content	23 g/L (ASTM D3960 / D2369, FORAY NATA 1231 Certificate P22070055)
EP250 Application Temperature	10-26C, ambient and substrate
EP250 Cure Before Overcoating	Minimum 24 hours at 25C, 50% RH
Slip Resistance	Not rated as supplied, an anti-slip broadcast is required to achieve a designed rating
Hazard Classification	ULTRA SHIELD Part B is a flammable liquid and vapour and dangerous goods; both EP250 parts are hazardous chemicals and Part B is dangerous goods
* Typical Forspec R&D characteristic values - no accredited certificate is currently held for ACTFLEX ULTRA SHIELD
