What makes Hydrotite different from PVC waterstops?

Hydrotite is a self-adhesive, co-extruded hydrophilic rubber strip that swells when wet to seal the joint. There is no site welding, no special intersections and it can be bonded to rough surfaces or even to existing PVC waterstops.

How is Hydrotite installed?

Peel the release film and press the strip onto a clean, dry construction joint surface. On rough or uneven concrete, bed it with Leakmaster LV-Z gun-grade waterstop. Lengths are simply butt-joined.

Will Hydrotite expand prematurely if the joint gets wet during construction?

The delay coating slows the initial swell so the strip can be cast in without premature expansion. It also performs reliably through repeated wet/dry cycles in service.

Is Hydrotite compatible with drinking water?

Yes. Hydrotite is certified to AS 4020:2018 for products in contact with drinking water, making it suitable for water tanks, reservoirs and treatment plants.

Is Hydrotite safe to handle?

Yes. It is non-toxic and non-hazardous, with no site welding or solvents required. Standard construction PPE is sufficient.

Be the first to review

5+ bought this month

Parchem Hydrotite Waterstop

Name: Parchem Hydrotite Waterstop
Brand: Fosroc
SKU: PPAF30
Price: 360.00 AUD
Availability: InStock

$360.00

or 4 interest-free payments with

PVC waterstop strip for preventing water ingress at construction joints. Durable and flexible.

Parchem HYDROTITE is a flexible PVC strip cast into concrete at construction joints. It prevents water seeping through joints and cracks during hydrostatic pressure.

What it's for

Construction joints in concrete foundations, basements and retaining walls
Horizontal and vertical joints subject to hydrostatic pressure
Use with sealant in the sealing groove for complete waterproofing

Why waterproofers buy it

Flexible design adapts to concrete movement and shrinkage
Prevents water ingress at construction joints under pressure
Simple installation: embed in concrete before casting
Long term durability. Does not absorb water or degrade
Works with standard concrete placement techniques

Not for

Expansion joints (use separate sealant), areas with high dynamic movement, or above-water applications without additional sealant.

Self-adhesive backing means no separate construction adhesive is needed

Expands up to 500% in volume and seals heads of water up to 50m

Butt joins only, with no site welding and no special intersection pieces

Quantity: 1

7-Day Money BackGuarantee

Fast DispatchNext Business Day

Expert Advice(02) 8021 3517

Secure CheckoutSSL Encrypted

Get it — —

Pickup available at The Waterproofing Shop

Usually ready in 24 hours

Parchem Hydrotite Waterstop

The Waterproofing Shop

Pickup available, usually ready in 24 hours

22/872 Canterbury Road
Roselands NSW 2196
Australia

+61280213517

Product Details

With its self-adhesive backing, installation is quick and hassle-free, saving you time and effort. Hydrotite Waterstop ensures long-lasting performance, even in challenging environments. Benefit from its superior flexibility, durability, and resistance to UV rays, chemicals, and extreme temperatures. Suitable for various applications, including basements, tunnels, dams, and water treatment plants, this self-adhesive waterstop guarantees superior waterproofing results, offering peace of mind and protection for your structures.

How to Use

Peel the backing paper off a section at a time and press the strip firmly onto clean dry concrete; bed it into Leakmaster gun grade waterstop on rough surfaces.Prepare a clean, dry, smooth surface, not scabbled, free from oils, grease, dust and debris, similar to a wood float or off-form finish
Repair air holes 4-5mm in diameter or depth with a suitable repair mortar
Set the waterstop out so a minimum of 100mm cover of concrete is present over the strip
Cut the ends square with a sharp knife or scissors so every join is a neat, firm butt join
Lay the strip along the clean dry concrete next to where it is to be installed
Peel the protective backing paper off a section at a time, turn the strip over and press firmly down so it is fully bonded to the concrete
On rough surfaces, gun Leakmaster onto the clean dry surface to build the rough concrete up to a smooth surface and fill the imperfections
Press the strip down into the Leakmaster with moderate hand pressure until the Leakmaster oozes out and there are no visible gaps
On vertical applications use concrete nails in conjunction with the Leakmaster, taking care not to cause cracking in the concrete
Butt join all lengths firmly end to end and place a bead of Leakmaster across every join
Cut and butt join at every 90 degree angle rather than pulling the strip around the corner
Leave a 100mm tail to allow butt joining to the next pour
Protect the installed strip from moisture and ponding water and check for pre-expansion, dark blue turning light blue, before pouring
Do not place concrete until the Leakmaster has cured sufficiently to avoid displacement during the pour
Place and fully compact the second pour so the waterstop is fully encapsulated

Technical Specifications

Classification: Hydrophilic (water swellable) waterstop for cast in-situ concrete
Chemical Base: Expanding hydrophilic material co-extruded with non-expanding chloroprene rubber
Colour: Expanding section blue, non-expanding section black; turns light blue when it starts to expand
Backing: Self-adhesive backing on most rectangular profiles
Surface Treatment: Delay coating to help prevent premature expansion
Volume Expansion: Minimum 500%, in house test*
Hydrostatic Head: Seals heads of water up to 50m*
Hardness (JIS-A): 50 +/- 5, JIS K 6253*
Tensile Strength: Minimum 2.00 N/mm2 hydrophilic rubber, JIS K 6251*
Elongation: Minimum 550% hydrophilic rubber, JIS K 6251*
Minimum Concrete Cover: 100mm over the waterstop, based on concrete strength of 22.5N/mm2
Jointing: Simple butt joins, no site welding and no special intersections
Profiles: CJ0725-3K 7mm x 25mm, CJ1020-2K 10mm x 20mm, DSS0220 2mm x 20mm, RSS rods 16mm to 25mm diameter
Roll Lengths: 10m for CJ0725-3K and CJ1020-2K, 25m for DSS0220, 10m for RSS1610D, RSS2014D and RSS2205D, 5m for RSS2519D
Standards Compliance: AS/NZS 4020:2018, AWQC Report 308541
Shelf Life: 3 years from date of manufacture
Hazard Classification: Not classified as hazardous, not classified as Dangerous Goods
* Manufacturer published values to the stated test methods; the only accredited report held is the AWQC AS/NZS 4020 potable water report

Product Files

Parchem Hydrotite Waterstop

$360.00

Frequently bought together

This item

Parchem Hydrotite Waterstop $360.00
Add

Parchem Leakmaster LV-Z 320mL $62.00

Technical overview

Hydrotite is a hydrophilic waterstop manufactured by C.I. Takiron Corp. and distributed in Australia by Parchem. It expands in a controlled manner in the presence of moisture to create a pressure seal within construction joints in concrete structures, increasing in volume up to 500% and sealing heads of water up to 50 metres. A delay coating limits premature expansion before the second pour, and the co-extruded blue hydrophilic and black chloroprene sections direct the expansion across the joint. Hydrotite holds an accredited AWQC report (308541) confirming compliance with AS/NZS 4020:2018 for contact with drinking water. It is designed for in-situ concrete only, is not suitable for masonry or blockwork, and is generally not suitable for expansion joints.

View full technical data sheet

Key applications

Construction joints for in-situ concrete
Sewerage and water treatment plants
Pipe penetrations
Subway stations
Swimming pools
Basements
Reservoirs
Tunnels
Pits
Thru tie (tie bolt) holes, using RSS rod profiles

Surface suitability

Cast in-situ concrete construction joints (clean, dry, smooth surface, not scabbled, free from oils, grease, dust and debris)
Joints between new and existing concrete where there is little or no steel continuity
Rough concrete surfaces (bedded into Leakmaster gun grade waterstop)
Pipe penetrations, prior to concrete placement
Thru tie (tie bolt) holes, using RSS rod profiles

Designed for use in in-situ concrete only and not suitable for masonry or blockwork construction. Not recommended for use in suspended slabs or expansion joints, and not for use where excessive shrinkage or movement may occur. A minimum of 100mm cover of concrete is required over the waterstop, based on concrete strength of 22.5N/mm2. Expansion rate can vary in salt or contaminated water. Protect from moisture or ponding of water prior to placement of concrete to avoid pre-expansion; if it has already expanded too much, remove the strip and replace it with new material. Nailing is not recommended unless used with adhesive. Store in a cool, dark, dry space and do not expose to water or sunlight.

Calculate your coverage

Enter area to cover (m²) m² Number of coats

You will need:

Parchem Hydrotite Waterstop

10m profile)

0 Kits

Total coverage: 0 m²

This is an estimate only. Add 10% for wastage.

Technical Specifications

Classification	Hydrophilic (water swellable) waterstop for cast in-situ concrete
Chemical Base	Expanding hydrophilic material co-extruded with non-expanding chloroprene rubber
Colour	Expanding section blue, non-expanding section black; turns light blue when it starts to expand
Backing	Self-adhesive backing on most rectangular profiles
Surface Treatment	Delay coating to help prevent premature expansion
Volume Expansion	Minimum 500%, in house test*
Hydrostatic Head	Seals heads of water up to 50m*
Hardness (JIS-A)	50 +/- 5, JIS K 6253*
Tensile Strength	Minimum 2.00 N/mm2 hydrophilic rubber, JIS K 6251*
Elongation	Minimum 550% hydrophilic rubber, JIS K 6251*
Minimum Concrete Cover	100mm over the waterstop, based on concrete strength of 22.5N/mm2
Jointing	Simple butt joins, no site welding and no special intersections
Profiles	CJ0725-3K 7mm x 25mm, CJ1020-2K 10mm x 20mm, DSS0220 2mm x 20mm, RSS rods 16mm to 25mm diameter
Roll Lengths	10m for CJ0725-3K and CJ1020-2K, 25m for DSS0220, 10m for RSS1610D, RSS2014D and RSS2205D, 5m for RSS2519D
Standards Compliance	AS/NZS 4020:2018, AWQC Report 308541
Shelf Life	3 years from date of manufacture
Hazard Classification	Not classified as hazardous, not classified as Dangerous Goods
* Manufacturer published values to the stated test methods; the only accredited report held is the AWQC AS/NZS 4020 potable water report

Frequently asked questions

View all FAQs

What makes Hydrotite different from PVC waterstops?

Application
Hydrotite is a self-adhesive, co-extruded hydrophilic rubber strip that swells when wet to seal the joint. There is no site welding, no special intersections and it can be bonded to rough surfaces or even to existing PVC waterstops.
How is Hydrotite installed?

Application
Peel the release film and press the strip onto a clean, dry construction joint surface. On rough or uneven concrete, bed it with Leakmaster LV-Z gun-grade waterstop. Lengths are simply butt-joined.
Will Hydrotite expand prematurely if the joint gets wet during construction?

Performance
The delay coating slows the initial swell so the strip can be cast in without premature expansion. It also performs reliably through repeated wet/dry cycles in service.
Is Hydrotite compatible with drinking water?

Compatibility
Yes. Hydrotite is certified to AS 4020:2018 for products in contact with drinking water, making it suitable for water tanks, reservoirs and treatment plants.
Is Hydrotite safe to handle?

Safety
Yes. It is non-toxic and non-hazardous, with no site welding or solvents required. Standard construction PPE is sufficient.

Why trade professionals choose Fosroc

Fosroc is a construction chemicals brand supplied to the Australian trade, best known on site for below-grade and joint sealing work. The range we carry is focused on that job: Supercast Hydrofoil, Hydrotite Waterstop and Leakmaster LV-Z, for basements, retaining walls, lift pits and construction joints. Order online for delivery Australia wide, or call our team if you need help matching a product to an engineer's detail.
