Waterproofing Standards Are Evolving — Why Full System Compatibility Testing Is Now Critical

The waterproofing industry is rapidly evolving, and compliance expectations are becoming significantly more demanding than ever before.

For many years, waterproofing membranes were often assessed as standalone products. If the membrane passed waterproofing performance requirements, it was considered suitable for use beneath tiles in internal wet areas.

That is now changing.

The industry is moving toward full system compatibility testing, with increasing focus being placed on the adhesion relationship between:

• the substrate
• the waterproofing membrane
• the tile adhesive
• the tiled finish system

This shift is largely driven by the increasing importance of AS ISO 13007 standards, particularly around bond strength, adhesion performance, deformability, and long-term system durability under real-world conditions.

This is especially important because one of the most common causes of waterproofing failure does not actually occur within the membrane itself.

It occurs at the membrane-to-adhesive interface.

When tile adhesives cannot properly bond to waterproofing membranes, failures can occur including:

• tile drumming
• debonding
• delamination
• movement failure
• moisture ingress
• cracked grout
• loose tiles
• complete system failure

As compliance expectations continue evolving, simply having a waterproofing membrane that is waterproof is no longer enough.

The membrane must now work as part of a complete compatible tiling system.

This is where FORSPEC Protective Coatings has positioned itself ahead of much of the industry.

The Shift Toward Complete Compatibility Chain Testing

Modern waterproofing systems are no longer being viewed as isolated products.

Instead, regulators, builders, consultants, certifiers, and specifiers are increasingly looking at the performance of the complete installed assembly.

This includes:

1. Substrate preparation
2. Waterproofing membrane adhesion
3. Tile adhesive compatibility
4. Tile system performance
5. Long-term movement capability
6. Wet area durability
7. Bond strength retention over time

The major concern is simple:

A waterproofing membrane may perform perfectly as a waterproof barrier, but if the tile adhesive cannot maintain proper adhesion to the membrane surface, the entire system becomes compromised.

This has become particularly important with polyurethane membranes used internally beneath tiles.

Many polyurethane systems can create adhesion challenges with cement-based tile adhesives unless:

• the membrane chemistry is compatible
• the membrane surface profile is suitable
• the adhesive system is specifically tested
• the complete assembly demonstrates compliant bond strength performance

Without verified compatibility testing, long-term performance risks increase significantly.

Why Bond Strength Testing Is Becoming So Important

The industry is now placing increasing emphasis on adhesion testing and bond strength verification because tiled waterproofing systems are exposed to constant stresses including:

• thermal expansion
• contraction
• moisture cycling
• cleaning chemicals
• movement in substrates
• vibration
• structural settlement
• hydrostatic exposure
• heat ageing
• long-term moisture exposure

If the adhesive-to-membrane bond is weak, these stresses eventually cause failure.

This is why AS ISO 13007 testing is becoming such a major part of modern compliance discussions.

These standards evaluate whether a tile adhesive can maintain sufficient performance under various environmental and ageing conditions.

Testing includes:

• Initial tensile adhesion strength
• Adhesion after water immersion
• Adhesion after heat ageing
• Adhesion after freeze/thaw cycling
• Open time adhesion performance
• Deformability testing

These tests are designed to simulate real-world conditions over time.

The result is a far more reliable understanding of whether the adhesive and membrane system will continue performing long after installation.

FORSPEC’s Tested Compatibility Chain

FORSPEC Protective Coatings has invested heavily into developing and testing a complete compatible system approach.

This compatibility chain includes:

• ACTFLEX 989 CWP
• ACTFLEX 906 WPU
• ACTFLEX BIOSET Tile Adhesive

Rather than simply testing products independently, FORSPEC has focused on ensuring the waterproofing membrane and tile adhesive work together as a complete system.

This is extremely important.

Many manufacturers produce waterproofing membranes.

Many manufacturers produce tile adhesives.

Very few manufacturers actually test the adhesion compatibility between the two systems together.

FORSPEC has now established a tested compatibility pathway between:

• membrane chemistry
• adhesive chemistry
• adhesion performance
• deformability performance
• long-term bond strength retention

This provides builders, applicators, consultants, and specifiers with significantly greater confidence in long-term system performance.

ACTFLEX 906 WPU — High Performance Polyurethane Waterproofing Membrane

ACTFLEX 906 WPU is a high-performance polyurethane waterproofing membrane designed for demanding internal and external waterproofing applications.

Polyurethane membranes are known for:

• excellent flexibility
• elongation capability
• crack bridging performance
• durability
• movement accommodation
• long-term waterproofing performance

However, polyurethane membranes have historically presented challenges when used beneath tiles internally if proper adhesive compatibility is not achieved.

Some polyurethane membranes can create low surface adhesion characteristics that reduce the ability for cementitious tile adhesives to properly bond long term.

This is why compatibility testing is becoming increasingly critical.

ACTFLEX 906 WPU has now been tested within a compatible adhesive system using ACTFLEX BIOSET Tile Adhesive to ensure strong adhesion performance and long-term compatibility between the membrane and adhesive system.

This provides a compliant and tested system pathway for tiled waterproofing applications.

ACTFLEX 989 CWP — Advanced Cementitious Waterproofing Technology

ACTFLEX 989 CWP is a high-performance cementitious waterproofing membrane designed for both positive and negative hydrostatic waterproofing applications.

The system provides:

• strong substrate adhesion
• flexibility
• crack bridging capability
• anti-efflorescence protection
• hydrostatic pressure resistance
• compatibility with tiled finishes

Because cementitious membranes form part of the substrate interface beneath adhesives, adhesion compatibility with tile adhesives becomes critical for long-term tiled system performance.

ACTFLEX 989 CWP has now also formed part of FORSPEC’s tested compatibility chain with ACTFLEX BIOSET Tile Adhesive, ensuring the membrane and adhesive system perform together under demanding conditions.

This creates a complete membrane-to-adhesive system pathway rather than isolated individual products.

Introducing ACTFLEX BIOSET Tile Adhesive

ACTFLEX BIOSET is FORSPEC’s high-performance cementitious tile adhesive developed for modern waterproofing and tiling systems requiring strong adhesion performance, deformability, and long-term reliability.

The adhesive has now successfully completed the full AS ISO 13007.2 testing suite.

The testing achieved:

• C2 Classification
• S1 Deformable Classification

This is a major achievement.

C2 classification confirms improved cementitious adhesive performance.

S1 classification confirms deformability performance, meaning the adhesive can accommodate movement within the system without failure.

This becomes critical in waterproofed tiled environments where thermal movement and substrate movement are common.

Verified AS ISO 13007.2 Test Results

ACTFLEX BIOSET achieved the following verified test results:

Initial Tensile Adhesion Strength

2.194 N/mm²

Tensile Adhesion After Water Immersion

1.453 N/mm²

Tensile Adhesion After Heat Ageing

1.771 N/mm²

Tensile Adhesion After Freeze/Thaw Cycling

1.449 N/mm²

Open Time Adhesion Performance

0.856 N/mm²

Transverse Deformation

3.270 mm (S1 Classification)

These results demonstrate strong adhesion retention under multiple environmental conditions and long-term stress simulations.

The testing confirms the adhesive can maintain strong performance not only initially, but also after exposure to:

• water
• heat
• ageing
• thermal cycling
• movement stress

This is exactly what modern tiled waterproofing systems require.

The testing report was conducted by XTec Gen Pty Ltd under accredited laboratory conditions to AS ISO 13007.2 requirements.

How The Full FORSPEC System Works Together

The strength of the FORSPEC system is not simply the membrane.

It is the compatibility between every layer of the installation system.

The complete assembly works together as follows:

1. Substrate

The substrate provides the structural base.

Proper preparation ensures suitable adhesion and mechanical stability.

2. Waterproofing Membrane

ACTFLEX 906 WPU or ACTFLEX 989 CWP provides:

• waterproofing protection
• crack bridging
• movement accommodation
• moisture protection

These membranes form the waterproof barrier beneath the tiled system.

3. Tile Adhesive

ACTFLEX BIOSET is applied directly over the membrane.

Because the adhesive has been tested for adhesion performance and compatibility, strong long-term bonding can be achieved between:

• membrane surface
• adhesive layer
• tile system

4. Tiled Finish System

The tiled finish becomes mechanically supported by the complete compatible assembly underneath it.

Instead of each product working independently, the full system performs together as one engineered installation.

This is the future direction of waterproofing compliance.

Why This Matters For Builders, Applicators, and Specifiers

The industry is moving toward greater accountability.

Builders and consultants increasingly want tested systems rather than isolated products.

A tested compatibility chain provides:

• greater specification confidence
• reduced liability risk
• improved long-term durability
• verified adhesion performance
• reduced failure risk
• increased compliance confidence
• stronger technical support pathways

As standards continue evolving, compatibility testing between waterproofing membranes and tile adhesives will likely become increasingly important across the Australian construction industry.

FORSPEC has already invested into this future direction.



The Future Of Waterproofing Systems

The waterproofing industry is changing rapidly.

The future will not simply be about waterproof membranes.

It will be about complete tested systems.

Systems where:

• membrane chemistry
• adhesive chemistry
• movement capability
• bond strength
• deformability
• durability
• long-term performance

are all tested together.

FORSPEC Protective Coatings is proud to be among the companies investing in this next generation of waterproofing compliance and compatibility testing.

With:

• ACTFLEX 906 WPU
• ACTFLEX 989 CWP
• ACTFLEX BIOSET Tile Adhesive

FORSPEC now offers a tested compatibility chain designed for evolving industry expectations and long-term system performance.

Build Better.
Build With Confidence.
Build With FORSPEC.
