ACTFLEX 5000: Your Go-To Solution for Advanced Waterproofing
When it comes to waterproofing, ACTFLEX 5000 delivers unmatched performance and durability. Designed for demanding construction projects, this high-performance, self-adhesive membrane features a polymer resin base, significantly enhancing both environmental friendliness and overall performance compared to traditional asphalt membranes.
With its reinforced cross-laminated high-density polyethylene film, ACTFLEX 5000 ensures exceptional waterproofing capabilities. The self-adhesive salvage edge allows seamless overlaps for a watertight seal, and the membrane can be applied in both wet and dry conditions, making it perfect for:
- Basement walls
- Retaining walls
- External lift shafts
- Non-exposed rooftops
Why ACTFLEX 5000?
Key Advantages:
- Superior Adhesion: Forms a strong mechanical lock with concrete for enhanced durability.
- Enhanced Durability: Twice the national standard for degradation strength, ensuring lasting adhesion.
- Improved Flexibility: Accommodates structural movement without compromising integrity.
- Active Waterproofing: Immediate adhesion upon treatment for fast and effective waterproofing.
- Versatile Application: Suitable for both wet and dry installation, covering a wide range of project needs.
- User-Friendly Installation: Easy to apply without specialized equipment or open flames, making it accessible for all users.
- Wide Application Range: Ideal for underground, indoor works, and projects where open flames are prohibited.
- Excellent Chemical Resistance: Resists a wide range of chemicals, ensuring durability in tough environments.
- Weather-Resistant: Maintains performance across various weather conditions.
- One-Day Application: Apply and complete your waterproofing project in just one day.
- Self-Sealing on Contact: Ensures a watertight seal as soon as it touches the substrate.
- Consistent Membrane Thickness: Delivers uniform performance throughout the installation.
Technical Properties:
- Peel Strength: 5.28 N/mm
- Puncture Resistance: 370 N
- Tensile Strength: 4.89 MPa (lengthways), 4.61 MPa (transverse)
- Elongation at Break: 310% (lengthways), 280% (transverse)
- Total Thickness: 1.55 mm
- Water Vapor Transmission Rate: 0.043 g/(m²·h)
- Low-Temperature Flexibility: No visual cracks under ASTM D1970/D1970M-15 testing
Ideal Applications:
ACTFLEX 5000 excels in external wet areas like basements, retaining walls, and non-exposed rooftops. The membrane’s high rubber content and advanced polymer resin base ensure superior waterproofing and long-lasting protection, making it the perfect choice for:
- Non-exposed underground structures
- External walls (basement, retaining)
- Lift shafts
- Indoor and outdoor areas where fire hazards prohibit open flames
- Applications requiring chemical resistance and weather resilience
How to Apply on Concrete and Masonry Substrates:
ACTFLEX 5000 is designed for easy application on concrete and masonry. Simply apply it to prepared surfaces, ensuring proper overlap on the self-adhesive salvage edge for a watertight finish. The membrane can also be applied in both wet and dry conditions, making it adaptable to various job site needs.
