ACTFLEX 5000: Your Go-To Solution for Advanced Waterproofing

When it comes to waterproofing, ACTFLEX 5000 delivers unmatched performance and durability. Designed for demanding construction projects, this high-performance, self-adhesive membrane features a polymer resin base, significantly enhancing both environmental friendliness and overall performance compared to traditional asphalt membranes.

With its reinforced cross-laminated high-density polyethylene film, ACTFLEX 5000 ensures exceptional waterproofing capabilities. The self-adhesive salvage edge allows seamless overlaps for a watertight seal, and the membrane can be applied in both wet and dry conditions, making it perfect for:

• Basement walls
• Retaining walls
• External lift shafts
• Non-exposed rooftops

Why ACTFLEX 5000?

Key Advantages:

• Superior Adhesion: Forms a strong mechanical lock with concrete for enhanced durability.
• Enhanced Durability: Twice the national standard for degradation strength, ensuring lasting adhesion.
• Improved Flexibility: Accommodates structural movement without compromising integrity.
• Active Waterproofing: Immediate adhesion upon treatment for fast and effective waterproofing.
• Versatile Application: Suitable for both wet and dry installation, covering a wide range of project needs.
• User-Friendly Installation: Easy to apply without specialized equipment or open flames, making it accessible for all users.
• Wide Application Range: Ideal for underground, indoor works, and projects where open flames are prohibited.
• Excellent Chemical Resistance: Resists a wide range of chemicals, ensuring durability in tough environments.
• Weather-Resistant: Maintains performance across various weather conditions.
• One-Day Application: Apply and complete your waterproofing project in just one day.
• Self-Sealing on Contact: Ensures a watertight seal as soon as it touches the substrate.
• Consistent Membrane Thickness: Delivers uniform performance throughout the installation.

Technical Properties:

• Peel Strength: 5.28 N/mm
• Puncture Resistance: 370 N
• Tensile Strength: 4.89 MPa (lengthways), 4.61 MPa (transverse)
• Elongation at Break: 310% (lengthways), 280% (transverse)
• Total Thickness: 1.55 mm
• Water Vapor Transmission Rate: 0.043 g/(m²·h)
• Low-Temperature Flexibility: No visual cracks under ASTM D1970/D1970M-15 testing

Ideal Applications:

ACTFLEX 5000 excels in external wet areas like basements, retaining walls, and non-exposed rooftops. The membrane’s high rubber content and advanced polymer resin base ensure superior waterproofing and long-lasting protection, making it the perfect choice for:

• Non-exposed underground structures
• External walls (basement, retaining)
• Lift shafts
• Indoor and outdoor areas where fire hazards prohibit open flames
• Applications requiring chemical resistance and weather resilience

How to Apply on Concrete and Masonry Substrates:

ACTFLEX 5000 is designed for easy application on concrete and masonry. Simply apply it to prepared surfaces, ensuring proper overlap on the self-adhesive salvage edge for a watertight finish. The membrane can also be applied in both wet and dry conditions, making it adaptable to various job site needs.
