Forspec ACTFLEX 5000 self-adhesive waterproofing membrane roll measuring 20m x 1m, reinforced for below-ground waterproofing, retaining walls, basements, podium decks, and concrete structures.
Be the first to review

ACTFLEX 5000 20m x 1m Self-Adhesive Waterproofing Sheet Membrane

Sale price$605.00
or 4 interest-free payments with

Peel-and-stick sheet membrane for basements and retaining walls. No torch, no bitumen, goes down wet or dry.

ACTFLEX 5000 is a self-adhesive sheet membrane on a non-asphalt polymer resin base with cross-laminated HDPE reinforcement. It locks into the concrete with no torch and no bitumen odour or staining, and the factory selvedge gives a watertight lap without site adhesives. 1 m x 20 m roll.

Where to use it

  • Basement walls and below-ground structures
  • Retaining walls and foundation walls
  • Planter boxes and landscaped areas that need root resistance
  • External lift shaft walls
  • Covered rooftop and deck areas, and any site where open flame is banned

Why waterproofers buy it

  • Peel and stick. Fast, clean, no hot work
  • Installs wet or dry, so the weather does not stop the job
  • Cross-laminated HDPE for puncture resistance in both axes
  • Non-asphalt resin locks into the concrete. No bitumen odour or staining
  • Chemical resistant for aggressive ground. Root resistant for planters
  • Adhesion is immediate on pressure rolling. Backfill or protection board straight after inspection
  • 10 year Forspec product warranty

Coverage

1 m x 20 m roll, 20 m² gross. Deduct 75 mm on every side and end lap. Take-off is measured area plus upturns, plus 20% for laps and wastage.

Not for

Exposed use (cover it with protection, backfill, topping or finish, it is not UV stable), exposed trafficable surfaces, structural crack repair, frosted substrates, standing water or sharp projections, or installing below 5°C without a trial area. Where a bonded topping slab needs chemical fusion to the membrane, use ACTFLEX 5000S.

Peel-and-stick install with no torch, flame or hot work
Cross-laminated HDPE reinforcement resists puncture in both axes
Root resistant, suited to planter boxes and landscaped areas
7-Day Money Back 7-Day Money BackGuarantee
Fast Dispatch Fast DispatchNext Business Day
Expert Advice Expert Advice(02) 8021 3517
Secure Checkout Secure CheckoutSSL Encrypted
Get it — —

Pickup available at The Waterproofing Shop

Usually ready in 24 hours

Forspec ACTFLEX 5000 self-adhesive waterproofing membrane roll measuring 20m x 1m, reinforced for below-ground waterproofing, retaining walls, basements, podium decks, and concrete structures.

ACTFLEX 5000 20m x 1m Self-Adhesive Waterproofing Sheet Membrane

The Waterproofing Shop

Pickup available, usually ready in 24 hours

22/872 Canterbury Road
Roselands NSW 2196
Australia

+61280213517
ACTFLEX 5000 20m x 1m Self-Adhesive Waterproofing Sheet Membrane
$605.00

Frequently bought together

System Build-Up Guide

Correct application makes all the difference.

View All Details

Pool System Build-Up

  • 1 Concrete Substrate
  • 2 Crack Repair (if required)
  • 3 ACTFLEX FLEXPLUS
  • 4 ACTFLEX HYDROPLUG
  • 5 ACTFLEX AT MESH
  • 6 ACTFLEX 988 CWP (2 Coats)
  • 7 Tile Adhesive
  • 8 Pool Finish
Pool System Build-Up

Retaining Wall System Build-Up

  • 1 Concrete Substrate
  • 2 Crack Repair (if required)
  • 3 ACTFLEX MS PRO
  • 4 ACTFLEX AT MESH
  • 5 ACTFLEX 988 CWP (2 Coats)
  • 6 Protection Board (Optional)
  • 7 Drainage System
  • 8 Backfill
Retaining Wall System Build-Up

Tank System Build-Up

  • 1 Concrete Substrate
  • 2 Crack Repair (if required)
  • 3 ACTFLEX FLEXPLUS
  • 4 ACTFLEX AT MESH
  • 5 ACTFLEX 988 WMP (2 Coats)
  • 6 Protective Coating (Optional)
  • 7 Water
Tank System Build-Up

Technical overview

ACTFLEX 5000 is a self-adhesive sheet waterproofing membrane built on a non-asphalt polymer resin base and reinforced with cross-laminated high-density polyethylene film. The factory self-adhesive selvedge edge produces a clean, watertight overlap without site adhesives or torching, and the sheet installs in both wet and dry conditions. It is used non-exposed on basement walls, planter boxes, retaining walls, external lift shaft walls and covered rooftop areas. Designed and manufactured to comply with AS/NZS 4858 and AS 4654.1, with verification testing to be commissioned. No accredited certificate is currently held on file for this product and all performance values are published as typical R&D characteristic values.

Key applications

  • Basement walls and below-ground structures
  • Planter boxes and landscaped areas requiring root resistance
  • Retaining walls and foundation walls
  • External lift shaft walls
  • Non-exposed rooftop and covered deck areas
  • External wet areas, non-exposed
  • Underground and external works where open flame is prohibited

Surface suitability

  • Concrete (structurally sound, minimum 28 days cured, free of standing water and frost)
  • Concrete (blowholes, voids, spalls and defects reinstated with FORBUILD 100 or FORCRETE 100, finished flush and cured)
  • Masonry and below-ground structures (clean, dry and free of bond-inhibiting contaminants)
  • Substrates with any specified primer applied and dry

Non-exposed applications only - ACTFLEX 5000 must be covered by the specified protection, backfill, topping or finish and must not be left permanently exposed to UV. Not for use as an exposed trafficable surface. Not a substitute for structural crack repair; active and structural cracks must be treated before the membrane is laid. Do not install over frosted substrates, standing water, or substrates with sharp projections or protruding fixings. Do not install below 5C without confirming adhesion on a trial area. Laps must be rolled and inspected - an unrolled lap is not a sealed lap. Where a bonded topping slab requires chemical fusion to the membrane surface, specify ACTFLEX 5000S instead.

Technical Specifications

Membrane ClassificationSelf-adhesive polymer resin sheet membrane
Chemical BaseNon-asphalt self-adhesive polymer resin
ReinforcementCross-laminated high-density polyethylene (HDPE) film
Edge DetailFactory self-adhesive selvedge
Roll Size20m x 1m (20m2 gross per roll)
Total Thickness1.55mm (ASTM D3767-03(2014) Procedure A)
Tensile Strength600 N/50mm minimum*
Elongation at Break150% minimum*
Puncture Resistance200 N minimum*
Nail Shank Tear Strength300 N minimum*
Low Temperature Flexibility-25C, no cracking*
Root ResistanceResistant - suitable for planter and landscaped applications*
Minimum Overlap75mm side and end laps*
Application ConditionWet or dry substrates
Application Temperature+5C to +35C*
Adhesion DevelopmentImmediate on pressure rolling - no cure period*
Ready for Protection Board or BackfillImmediately after inspection*
Shelf Life24 months unopened, stored dry and shaded*
* Typical Forspec R&D characteristic values

Real Projects. Real Results.

View All Projects
  • Pool Renovation Pool Renovation Before After

    Pool Renovation

    Gold Coast, QLD

  • Below Ground Retaining Wall Below Ground Retaining Wall Before After

    Below Ground Retaining Wall

    Sydney, NSW

  • Concrete Water Tank Concrete Water Tank Before After

    Concrete Water Tank

    Perth, WA

  • Commercial Podium Commercial Podium Before After

    Commercial Podium

    Melbourne, VIC

  • Before After

    Swimming Pool Construction

    Brisbane, QLD

Watch the install

Step-by-step from prep to top coat. Filmed on the tools, not in a studio.

Watch the install poster

The Waterproofing Shop?

We supply premium waterproofing products backed by expert advice, fast service and real-world experience.

100% Australian Owned & Operated 100% Australian
Owned & Operated
30+ Years in the Waterproofing Industry 30+ Years in the
Waterproofing Industry
Thousands of Products in Stock Thousands of Products
in Stock
Fast Shipping Australia Wide Fast Shipping
Australia Wide
Expert Technical Support Expert Technical
Support

Frequently asked questions

View all FAQs
  • What is ACTFLEX 5000 used for?
    Compatibility

    5000 is a self-adhesive HDPE-reinforced sheet membrane for below-grade waterproofing - basements, planter boxes, retaining walls, and root-resistant applications. Pressure-activated self-adhesion, no torching or solvents required.

  • What's the membrane construction?
    Performance

    5000 has a polymer resin layer with HDPE reinforcement (no asphalt). Total thickness 1.55mm including a 0.13mm surface film. Puncture resistance 370 N, elongation 310% transverse / 280% longitudinal.

  • How is it installed?
    Installation

    Lay the membrane against the substrate (no primer needed), peel the release liner, and press into place. The self-adhesive backing activates under pressure. 20 m² per roll. Apply at standard ambient temperatures.

  • Is it root-resistant?
    Compatibility

    Yes. The HDPE reinforcement layer is permanently root-resistant - ideal for planter boxes, green roofs, and below-grade applications adjacent to landscaped areas. Class III certified.

  • What chemicals does it resist?
    Performance

    5000 resists acids, alkalis, salts, and most aggressive groundwater chemistry. The HDPE chemistry is inert to most soil contaminants found in urban below-grade applications. No asphalt means no creep or odour.
