Where do I use BRW PF Tape?

At wall-to-floor junctions, around pipe penetrations and flashings, sealing waterstops, patching metal surfaces and bondbreaker detailing prior to liquid membrane application.

Peel the release liner and press the tape firmly onto a clean dust-free substrate. Smooth with a hand roller to ensure full adhesion. No primer required on stable, dust-free surfaces.

What sizes are available?

80mm × 10m and 150mm × 10m rolls. The store carries the standard 80mm wide format used in residential bathroom systems.

Can I cover it with a Gripset liquid membrane?

Yes – it is fully compatible with Gripset 38FC, P39, 2P, C-1P, LS and Xpress Multi Pro Membrane systems.

How soon can I coat over it?

It is instantly bonded and waterproof – overcoat with the Gripset membrane straight after application.

How should I store the roll?

Store flat in a cool dry place out of direct sunlight. Reseal the inner sleeve between uses to keep the adhesive face clean.

GRIPSET BRWPF self-adhesive butyl rubber sealing tape measuring 5m x 80mm, designed to provide a flexible waterproof seal around joints, penetrations, flashings, and detailing on non-porous surfaces before waterproofing applications.

Be the first to review

5+ bought this month

Gripset BRW PF Tape Multipurpose Self-Adhesive Tape

$35.00

$39.00

LIMITED TIME DEAL

SAVE $4.00

or 4 interest-free payments with

Peel-and-stick butyl tape for flashing and detailing. Instant seal, no priming or drying time.

Gripset BRW PF Tape is a self-adhesive butyl sealing band, 0.8mm thick, in 80mm x 10m and 150mm x 10m rolls. It flashes and details joints and penetrations before you finish over the top, with no drying or curing wait.

Where to use it

Bondbreaker system to wall/floor junctions, joint intersections and transitions
Sealing puddle flanges, penetrations and waterstops
Detailing over plumbing pipes, PVC and flashings
Guttering and roofing
Patching pin holes and pitted areas on metal surfaces

Why waterproofers buy it

Instant seal, no drying or curing down time
Peel and stick application, primer-less on dust free, dry and stable surfaces
Sticks to primed or dense concrete, most metals, timber, compressed fibre cement sheeting, plasterboard, masonry, glazed surfaces, marble, granite, ceramics, plastics and polycarbonate
80mm x 10m and 150mm x 10m rolls, 0.8mm thick
Finished over with Gripset adhesives, membranes, coatings, mortars and renders
Best used within 12 months of purchase

Not for

Exposed flashing or exposed joint seals in external applications, must be finished over with a surface covering. Not to be used over expansion joints. Not to be used for sealing joints in negative hydrostatic applications. Cannot be applied over damp surfaces, seal with Gripset E60 first. Not compatible with solvent based materials applied directly over. Do not apply when surface temperature is below 5°C or above 30°C.

Instant seal with no drying or curing down time

Primer-less peel and stick on dust free, dry and stable surfaces

Compatible with Gripset liquid membranes and cement based finishes including tile adhesives and renders

Size: 80mm X 10m

80mm X 10m$35.00150MM X 10M$60.00

Quantity: 1

7-Day Money BackGuarantee

Fast DispatchNext Business Day

Expert Advice(02) 8021 3517

Secure CheckoutSSL Encrypted

Get it — —

Pickup available at The Waterproofing Shop

Usually ready in 24 hours

Gripset BRW PF Tape Multipurpose Self-Adhesive Tape

80mm X 10m

The Waterproofing Shop

Pickup available, usually ready in 24 hours

22/872 Canterbury Road
Roselands NSW 2196
Australia

+61280213517

Product Details

Excellent adhesion and flexible properties
Protection against moisture ingress, vibration and flexing
Creates an instant waterproof seal that can be finished over with Gripset membranes, coatings, mortars, adhesives and renders

Uses

Sealing roof sheet laps
Sealing holes and pitted areas in metal surfaces
Reinforcement bond breaker

How to Use

Cut to length, peel the release paper from the butyl side and press into place with a spatula or small vinyl roller with the fabric face upwardsConfirm all surfaces are clean, sound, smooth, dry and free of residual moisture, loose material, dirt, dust, oil, grease, wax residues, laitance, curing compounds, release agents, existing coatings, moss, algae and sharp protruding objects
Mechanically remove structurally unsound layers and surface contaminants by grinding, abrasive blasting or equivalent methods
Point masonry surfaces flush and fill and level voids, holes, pitted sections, heavy undulations and non-structural cracks
Confirm building surfaces are fit for purpose and installed to the manufacturer recommendations and the relevant building standards in force
Leave non porous and dense surfaces including metals and PVC plastics unprimed
Prime highly porous surfaces or surfaces containing dust or residues with Gripset GP, E60 or Xpress H20 Primer Plus
Use Gripset E60 on damp surfaces or surfaces containing high levels of residual moisture
Unroll the BRW PF Tape and measure the required length of joints or area to be sealed
Cut the tape using scissors or a sharp knife
Remove the release paper from the butyl rubber side and position the tape with the fabric face exposed upwards
Press into place with a spatula, small vinyl roller or similar, pushing out all air pockets and creases and achieving good connection to the substrate
For large runs over joint areas, remove the release paper gradually as the tape is unrolled and adhere into position
Apply finishes immediately after the tape is adhered in place
Finish over with Gripset adhesives, membranes, coatings, mortars and renders

Technical Specifications

Product Type: Multi-purpose self-adhesive butyl sealing band for flashing and detailing
Colour: Fabric face white, butyl backing grey
Thickness: 0.8mm
Solids: 100%
Specific Weight: 1.45g/cm3
Tensile Strength (EN 12311-1): Greater than 100N longitudinal and transverse directions
Elongation at Break (EN 12311-1): 70% longitudinal and transverse directions
Peel Adhesion (ASTM D1000): Greater than 80N
Loop Tack Test (ASTM D6195): Greater than 70N
Vertical Flow (ISO 7390): Less than 10mm
Service Temperature: -30C to 80C
Application Limit: Do not apply when surface temperature is below 5C or above 30C
Adhesion Development: Instant seal, no drying required
Roll Sizes: 80mm x 10m rolls and 150mm x 10m rolls, 0.8mm thick
Shelf Life: Best used within 12 months of purchase
Hazard Classification: NON-Hazardous, NON-Dangerous Goods (SDS)
TDS Revision: Issue date 01/10/2024

Product Files

Gripset BRW PF Tape Multipurpose Self-Adhesive Tape80mm X 10m

$35.00

Frequently bought together

This item

Gripset BRW PF Tape Multipurpose Self-Adhesive Tape $35.00
Add

Gripset BRW PF Square Multipurpose Self-Adhesive Sealing Square $9.70
Add

Gripset Elastoproof B10 / B50 Bond Breaker Joint Band $162.40
Add

ACTFLEX MS Pro Joint Sealant Modified Polyurethane $13.00

Technical overview

Gripset BRW PF Tape is a 0.8mm thick self-adhesive butyl sealing band for flashing and detailing internal and external surfaces that need protection against moisture ingress, vibration and flexing. It is supplied in 80mm x 10m and 150mm x 10m rolls and bonds to primed or dense concrete, most metals, timber, compressed fibre cement sheeting, plasterboard, masonry, glazed surfaces, marble, granite, ceramics, plastics and polycarbonate. It gives an instant seal with no drying or curing time and is designed to be finished over with Gripset adhesives, membranes, coatings, mortars and renders. The 01/10/2024 TDS publishes EN, ISO and ASTM test values but cites no test report number and no accredited certificate.

View full technical data sheet

Key applications

Bondbreaker system to wall/floor junctions, joint intersections/transitions
Sealing puddle flanges, penetrations and waterstops
Detailing over plumbing pipes, PVC, flashings etc.
Guttering and roofing
Patching pin holes and pitted areas on metal surfaces
General maintenance on surfaces to be covered over with surface finishes

Surface suitability

Primed or dense concrete
Galvanised iron, zincalume, copper, aluminium, Colorbond and most metals (free of oil, grease and wax residues)
Timber
Compressed fibre cement sheeting
Plasterboard
Masonry (pointed flush, voids and cracks filled and levelled)
Glazed surfaces
Marble, granite and ceramics
Plastics and polycarbonate
Highly porous surfaces or surfaces containing dust or residues (primed with Gripset GP, E60 or Xpress H20 Primer Plus)
Damp surfaces or surfaces containing high levels of residual moisture (sealed with Gripset E60)

Not to be used as an exposed flashing or exposed joint seal in external applications and must be finished over with a surface covering. Not to be used over expansion joints. Not to be used for sealing joints in negative hydrostatic applications. Cannot be applied over damp surfaces; damp surfaces must be sealed or primed with Gripset E60 before applying the tape. Not compatible with solvent based materials applied directly over. Do not apply when surface temperature is below 5C or above 30C.

Calculate your coverage

Enter area to cover (m²) m² Number of coats

You will need:

Gripset BRW PF Tape Multipurpose Self-Adhesive Tape

10m 10

0 Kits

Total coverage: 0 m²

This is an estimate only. Add 10% for wastage.

Technical Specifications

Product Type	Multi-purpose self-adhesive butyl sealing band for flashing and detailing
Colour	Fabric face white, butyl backing grey
Thickness	0.8mm
Solids	100%
Specific Weight	1.45g/cm3
Tensile Strength (EN 12311-1)	Greater than 100N longitudinal and transverse directions
Elongation at Break (EN 12311-1)	70% longitudinal and transverse directions
Peel Adhesion (ASTM D1000)	Greater than 80N
Loop Tack Test (ASTM D6195)	Greater than 70N
Vertical Flow (ISO 7390)	Less than 10mm
Service Temperature	-30C to 80C
Application Limit	Do not apply when surface temperature is below 5C or above 30C
Adhesion Development	Instant seal, no drying required
Roll Sizes	80mm x 10m rolls and 150mm x 10m rolls, 0.8mm thick
Shelf Life	Best used within 12 months of purchase
Hazard Classification	NON-Hazardous, NON-Dangerous Goods (SDS)
TDS Revision	Issue date 01/10/2024

Frequently asked questions

View all FAQs

Where do I use BRW PF Tape?

Application
At wall-to-floor junctions, around pipe penetrations and flashings, sealing waterstops, patching metal surfaces and bondbreaker detailing prior to liquid membrane application.
How is it applied?

Application
Peel the release liner and press the tape firmly onto a clean dust-free substrate. Smooth with a hand roller to ensure full adhesion. No primer required on stable, dust-free surfaces.
What sizes are available?

Compatibility
80mm × 10m and 150mm × 10m rolls. The store carries the standard 80mm wide format used in residential bathroom systems.
Can I cover it with a Gripset liquid membrane?

Compatibility
Yes – it is fully compatible with Gripset 38FC, P39, 2P, C-1P, LS and Xpress Multi Pro Membrane systems.
How soon can I coat over it?

Cure & Dry Time
It is instantly bonded and waterproof – overcoat with the Gripset membrane straight after application.
How should I store the roll?

Storage
Store flat in a cool dry place out of direct sunlight. Reseal the inner sleeve between uses to keep the adhesive face clean.
