Crack Injection 10mm Packers - 50 Pack
or 4 interest-free payments with
The 10 mm non-return packers the ACTFLEX PU200, PU300 and PU500 data sheets call for.
Crack Injection 10mm Packers are mechanical injection packers with non-return valves. They are the packer FORSPEC specifies for single-component, high-pressure polyurethane injection with ACTFLEX PU200, PU300 and PU500. Drill 10 mm, tighten with the T-handle wrench, inject.
What it's for
- Concrete crack injection with ACTFLEX PU200, PU300 and PU500
- Basements and underground structures, foundations, retaining walls and slabs
- Pre-wetting dry cracks by injecting clean water through the packer before the resin
Why waterproofers buy it
- Non-return valve holds the resin under pressure while it cures
- 10 mm body, matched to a 10 mm drill bit and a 10 mm T-handle wrench
- Remove after the resin reacts and patch the hole flush with FORBUILD 100 or FORCRETE 100
Specs
10 mm mechanical packer with non-return valve. Drill 10 mm holes at maximum 200 mm intervals, angled at 45 degrees. Leave about 20 mm proud.
Non-return valve holds the resin under pressure while it cures
10mm body matched to a 10mm drill bit and a 10mm T-handle wrench
Removable after the resin has fully reacted so the drill hole can be patched flush
7-Day Money BackGuarantee
Fast DispatchNext Business Day
Expert Advice(02) 8021 3517
Secure CheckoutSSL Encrypted
Get it
—
—
Pickup available at The Waterproofing Shop
Usually ready in 24 hours
Crack Injection 10mm Packers - 50 Pack
The Waterproofing Shop
22/872 Canterbury Road
Roselands NSW 2196
Australia
Product Details
Technical Specifications
Product Files
No documentation available for this product.
Crack Injection 10mm Packers - 50 Pack
Sale price$94.00
Frequently bought together
System Build-Up Guide
Correct application makes all the difference.
Retaining Wall System Build-Up
- 1 Concrete Substrate
- 2 Crack Repair (if required)
- 3 ACTFLEX MS PRO
- 4 ACTFLEX AT MESH
- 5 ACTFLEX 988 CWP (2 Coats)
- 6 Protection Board (Optional)
- 7 Drainage System
- 8 Backfill
Tank System Build-Up
- 1 Concrete Substrate
- 2 Crack Repair (if required)
- 3 ACTFLEX FLEXPLUS
- 4 ACTFLEX AT MESH
- 5 ACTFLEX 988 WMP (2 Coats)
- 6 Protective Coating (Optional)
- 7 Water
Key applications
- Concrete crack injection with single-component, high-pressure polyurethane injection equipment
- Injecting ACTFLEX PU200, PU300 and PU500 polyurethane resins into concrete cracks
- Structural epoxy crack injection with ACTFLEX ER300 through mechanical packers
- Basements and underground structures, stopping water ingress through foundations, retaining walls and slabs
- Tunnels and below-grade infrastructure, leak sealing in tunnels, subways and underground services
- Pre-wetting dry cracks by injecting clean water through the packers before resin injection
Surface suitability
- Concrete cracks in structural and non-structural elements, drilled at 10 mm
- Concrete foundations, retaining walls and slabs in basements and underground structures
Insert the packer into a clean, dust-free 10mm hole and leave approximately 20mm proud of the surface for connection and removal. Tighten each packer firmly with the T-handle wrench to seal against injection pressure. Do not over-inject: continue at each packer only until resin extrudes from the crack approximately 100mm either side of the packer, then move to the next packer. Injection into voids of unknown volume can consume large resin quantities, so probe and assess before injecting. Remove all packers after the resin has fully reacted and patch the drill holes flush with a FORSPEC repair mortar. Work to the Safety Data Sheet, PPE and pressure limits of the injection resin and pump being used, and never inject epoxy into an active running leak.
Technical Specifications
| Packer Type | Mechanical injection packer with non-return valve |
| Packer Diameter | 10 mm |
| Matching Drill Bit | 10 mm |
| Tightening Tool | T-handle wrench (10 mm) |
| Set Out | Approx. 20 mm left proud of the surface for connection and removal |
| Spacing, ACTFLEX PU200, PU300 and PU500 polyurethane injection | Maximum 200 mm along the crack |
| Spacing, ACTFLEX ER300 epoxy injection | 200 to 300 mm along the crack |
| Non-Return Function | Retains the resin under pressure while it cures |
| Removal | Removed after the resin has fully reacted, drill holes then patched flush with FORBUILD 100 or FORCRETE 100 |
| Source note | Specifications are taken from the FORSPEC injection resin Technical Data Sheets. No stand-alone data sheet is published for the packer itself. |
Real Projects. Real Results.
-
Before
After
Pool Renovation
Gold Coast, QLD
-
Before
After
Below Ground Retaining Wall
Sydney, NSW
-
Before
After
Concrete Water Tank
Perth, WA
-
Before
After
Commercial Podium
Melbourne, VIC
-
Before After
Swimming Pool Construction
Brisbane, QLD
Watch the install
Step-by-step from prep to top coat. Filmed on the tools, not in a studio.
The Waterproofing Shop?
We supply premium waterproofing products backed by expert advice, fast service and real-world experience.
100% AustralianOwned & Operated
30+ Years in theWaterproofing Industry
Thousands of Productsin Stock
Fast ShippingAustralia Wide
Expert TechnicalSupport
Frequently asked questions
-
What are these packers used for?
Compatibility10mm Crack Injection Packers are inserted into pre-drilled holes along a concrete crack to inject hydrophobic polyurethane (PU200/PU300), hydrophilic polyurethane (PU500/Injectswell), or epoxy resin (ER300, Crack Pro 1200) under pressure to seal the crack.
-
How are they installed?
InstallationDrill 10mm angled holes at 45 degrees across the crack at 100-150mm spacing, insert the packer, tighten the bolt to expand the rubber sleeve and grip the concrete, then attach the injection gun fitting and inject resin until refusal.
-
Are these single-use?
PerformanceYes. After injection, cut the packer flush to the concrete surface and patch with epoxy paste. The expanded rubber sleeve cannot be removed cleanly.
-
Which Forspec injection products work with these packers?
CompatibilityCompatible with the full ACTFLEX injection range: PU200, PU300, PU500, Injectswell, Crack Pro 1200PS, ProBond 1100PS, ER300, and Crack Lock E400L. Use the matching gun coupler for the injection pump.
-
How many packers per metre of crack?
PerformanceIndustry standard is 100-150mm spacing, giving 7-10 packers per metre of crack length. Drill on alternating sides of the crack at 45-degree opposing angles to intersect the crack at depth.
