How do I install BRW PFN?

Prime non-porous substrates with Xpress SP if needed, peel back the release liner and roll the sheet firmly onto the substrate. Use a hand roller to remove air and ensure full adhesion. Overlap joins by 50mm.

What substrates does it stick to?

Concrete, screed, fibre cement sheet, timber, metals, glazed surfaces, marble, granite, ceramics, plastics, PVC and existing epoxy coatings. Prime smooth/non-porous substrates with Xpress SP.

Is it certified for internal and external wet areas?

Yes – compliant to AS 4858 (internal wet areas) and AS 4654.1 (external above-ground waterproofing).

How soon can I tile over it?

BRW PFN is instantly waterproof once adhered – cement-based tile adhesives can be applied directly to the sheet face.

How much area does one roll cover?

Each roll is 1m × 10m = 10 m². Allow extra for 50mm overlaps at joins.

Are there fumes or solvents?

No – it is cold-applied, solvent free and non-toxic, with no torching or heat welding required.

Gripset BRW PFN Butyl Rubber Waterproofing Membrane 1mm x 1m x 10m Roll for waterproofing balconies, bathrooms, rooftops, wet areas, and below-ground applications, providing a durable self-adhesive waterproof barrier

Be the first to review

Gripset BRW PFN 1mm x 1m x 10m Roll

Name: Gripset BRW PFN 1mm x 1m x 10m Roll
Brand: Gripset
SKU: GGRG498
Price: 449.40 AUD
Availability: InStock

$449.40

or 4 interest-free payments with

Gripset BRW PFN self-adhesive butyl rubber sheet membrane, 1mm thick. Class II, floor areas only.

Gripset BRW PFN is a self-adhesive butyl rubber sheet membrane for high performance waterproofing over floor surfaces in internal and external areas. White face fabric with grey butyl backing, it features outstanding waterproof properties and enhanced resistance to vibration, movement and flexing, while supporting direct application of toppings and tiled finishes. Cold lay applied with no torching or heat welding. Class II, passes both AS4858 and AS 4654.1.

Where to use it

Internal wet areas: bathrooms, laundries and tiled areas
External wet areas: balconies, decks, podiums and terraces
Anti-fracture system over cracked concrete and floor substrates
Floor and horizontal surfaces only

Why waterproofers buy it

Self-adhesive, cold lay, no torching or heat welding
Class II membrane, passes AS4858 and AS 4654.1
Tensile strength greater than 2 MPa (AS 4654.1 Appendix A)
Elongation greater than 60 percent (AS1145.3)
Instant sealing properties, no drying or curing period
Minimum 50mm overlap on all sheet joins
Temperature service range -30C to 80C

Coverage

10m x 1m roll at 10 m2 gross area per roll. Approximately 9.5 m2 net per roll after minimum 50mm overlaps on all sheet joins.

Not for

Floor and horizontal surfaces only. Not for vertical surfaces. Do not apply below 5C or above 30C. Not as exposed finish, not as trafficable surface, not over expansion joints. Must be finished over with tiling or topping. When tiling, use polymer modified cement based adhesives only. Hazardous: may cause allergic skin reaction, causes serious eye irritation. Wear protective gloves and eye protection.

Gripset liquid membrane band 100mm wide mandatory over every sheet overlap.

Cold lay applied, ease of workability. No torching or heat welding

Excellent performance in low to high temperatures, -30C to 80C

Compliant to AS 4858 and AS4654.1 for internal and external wet areas

Quantity: 1

7-Day Money BackGuarantee

Fast DispatchNext Business Day

Expert Advice(02) 8021 3517

Secure CheckoutSSL Encrypted

Get it — —

Pickup available at The Waterproofing Shop

Usually ready in 24 hours

Gripset BRW PFN 1mm x 1m x 10m Roll

The Waterproofing Shop

Pickup available, usually ready in 24 hours

22/872 Canterbury Road
Roselands NSW 2196
Australia

+61280213517

How to Use

Cold lay peel and stick onto primed surfaces, removing creases and air bubbles with a flat trowel, heavy roller or float, with a minimum 50mm overlap at all sheet joins.Confirm all surfaces are clean, sound, smooth, dry and free from loose material, dirt, dust, oil, grease, wax residues, laitance, curing compounds, release agents, existing coatings, moss, algae and sharp protruding objects
Mechanically remove structurally unsound layers and surface contaminants by grinding, abrasive blasting or equivalent methods
Point masonry surfaces flush and fill and level all voids, holes, pitted sections, heavy undulations and non-structural cracks
Allow concrete to cure at least 28 days and cement render or sand cement screeds at least 7 days
Prime porous absorbent surfaces with Gripset GP Primer at a minimum 1litre/8-10m2, non porous surfaces with Gripset OP Primer at a minimum 1 litre per 12m2
For green or damp surfaces prime with Gripset Xpress H20 Primer Plus at 1 litre per 6m2, or Gripset E60 at 1 litre per 3m2 per coat and install the sheet within 72 hours of the dried film
Test and accept adhesion of the sheet over a small test area before applying to all surfaces
Measure the floor area, cut lengths with a sharp knife or scissors and re-roll the sheet ready for laying
Lay the first roll straight, using a string or laser line where it does not abut a wall surface
On sloped or graded surfaces start at the lowest point nearest the drainage point and work upwards so overlaps aid drainage
Remove approximately 100-200mm of release paper from the rear butyl rubber side, tack onto the surface and unroll, removing creases and air bubbles with a flat trowel, heavy roller or float
Ensure the sheet is well pressed at edges and termination points
Overlap all vertical and horizontal sheet joins a minimum 50mm and press with a small hand held vinyl roller
Coat all sheet overlaps with a 100mm wide liberal coat of a suitable Gripset liquid membrane applied centrally across the overlap
Cut the sheet over pipes, penetrations and fixtures, bond it around the fixture and seal with a liberal coat of a suitable Gripset liquid under tile membrane
Lay the sheet over floor wastes and adhere to both the floor surface and flange, then cut the aperture so the interface between substrate and floor waste is bridged and sealed
Detail perimeter wall and floor junctions with Elastoproof B50 Joint Band or BRW PF Tape, encapsulated in a Gripset liquid under tile membrane
Protect exposed terminated sheet edges with BRW PF Tape or RLA Waterproof Bandage and encapsulate with a Gripset liquid under tile membrane
Tile directly over the sheet using polymer modified cement based adhesives

Technical Specifications

Membrane Classification: Class II
Product Type: Self-adhesive butyl rubber sheet membrane with high tack butyl rubber backing and front fabric lamination
Colour/material: White face fabric, grey butyl backing
Thickness: 1mm
Specific Weight: 1.55g/cm3
Tensile Strength (AS 4654.1 Appendix A): Greater than 2MPa
Elongation (AS1145.3): Greater than 60%
Water Vapour Transmission (ASTM E96 Desiccant method): 0.1g.24h/m2
Water Absorption (AS 3558.1): 1.5%
Service Temperature: -30C to 80C
Compliance to AS4858: PASS
Compliance to AS 4654.1: PASS
Minimum Overlap: 50mm on all vertical and horizontal sheet joins, equal to 1 square of the fabric facing pattern
Adhesion Development: Instant sealing properties, no drying or curing period
Application Temperature: Do not apply when surface or ambient temperatures are below 5C or above 30C
Roll Size: 10m x 1m roll packed in cardboard cartons
Tiling Over: Polymer modified cement based adhesives only
Shelf Life: Best used within 12 months of purchase
Storage: Room temperature in dry internal conditions, stored upright vertically
Hazard Classification: Hazardous, NON-Dangerous Goods (SDS); Eye Irritation Category 2A, Skin Sensitisation Category 1
Composition: Ingredients determined to be non-hazardous, greater than 90% (SDS)
Specific Gravity: 1.4 - 1.7 (SDS)
Solubility: Immiscible with water (SDS)

Product Files

Gripset BRW PFN 1mm x 1m x 10m Roll

$449.40

Frequently bought together

This item

Gripset BRW PFN 1mm x 1m x 10m Roll $449.40
Add

Gripset 38FC Water-Based Membrane 15L $156.90
Add

Flood Test Balloon $28.00

Technical overview

Gripset BRW PFN is a self-adhesive butyl rubber sheet membrane for high performance waterproofing over floor surfaces in internal and external areas. A high tack butyl rubber backing and front fabric lamination give outstanding waterproof properties and resistance to vibration, movement and flexing, and support the direct application of toppings and tiled finishes. It is cold lay applied with no torching or heat welding, over primed surfaces, with a minimum 50mm overlap at all sheet joins. The TDS records a Class II membrane classification and a PASS against both AS4858 and AS 4654.1, with tensile strength to AS 4654.1 Appendix A and elongation to AS1145.3, but cites no accredited test report number, so all values are published as manufacturer test data.

Key applications

Internal wet areas, bathrooms, laundries and tiled areas
External wet areas, balconies, decks, podiums and terraces
Anti-fracture system over cracked concrete and floor substrates
Multi-layered high performance system with Gripset BRW-HD
Commercial, industrial and residential applications

Surface suitability

Concrete (allowed to cure for at least 28 days, primed with Gripset GP Primer at 1litre/8-10m2)
Screed and cement render (allowed to cure for at least 7 days, primed)
Compressed fibre cement sheeting (primed)
Timber sheeting and structural plywood (primed)
Most metals including galvanised iron, zincalume, stainless steel, copper and aluminium (priming generally not required when suitably prepared, sound and clean)
Glazed surfaces (priming generally not required when suitably prepared, sound and clean)
Marble, granite and ceramics
Soft and rigid plastics, PVC and DPC films (priming generally not required when suitably prepared, sound and clean)
Existing epoxy coatings
Non porous non absorbent surfaces (primed with Gripset OP Primer at 1 litre per 12m2)
Green or damp surfaces (primed with Gripset Xpress H20 Primer Plus at 1 litre per 6m2, or Gripset E60 at 1 litre per 3m2 per coat with the sheet installed within 72 hours of the dried film)

Suitable for floor and horizontal surfaces only. Not to be used over vertical surfaces to support tiles or other finishes. Do not apply when surface or ambient temperatures are below 5C or above 30C. Not to be used as an exposed membrane finish, it must be finished over. Not to be used as a trafficable surface. Not to be used over expansion joints. Not compatible with solvent based finishes applied over. When tiling directly over BRW PFN, polymer modified cement based adhesives must be used. Hazardous according to the criteria of Safe Work Australia GHS 7: may cause an allergic skin reaction and causes serious eye irritation. Wear protective gloves, protective clothing and eye/face protection.

Calculate your coverage

Enter area to cover (m²) m² Number of coats

You will need:

Gripset BRW PFN 1mm x 1m x 10m Roll

10m² 10

0 Kits

Total coverage: 0 m²

This is an estimate only. Add 10% for wastage.

Technical Specifications

Membrane Classification	Class II
Product Type	Self-adhesive butyl rubber sheet membrane with high tack butyl rubber backing and front fabric lamination
Colour/material	White face fabric, grey butyl backing
Thickness	1mm
Specific Weight	1.55g/cm3
Tensile Strength (AS 4654.1 Appendix A)	Greater than 2MPa
Elongation (AS1145.3)	Greater than 60%
Water Vapour Transmission (ASTM E96 Desiccant method)	0.1g.24h/m2
Water Absorption (AS 3558.1)	1.5%
Service Temperature	-30C to 80C
Compliance to AS4858	PASS
Compliance to AS 4654.1	PASS
Minimum Overlap	50mm on all vertical and horizontal sheet joins, equal to 1 square of the fabric facing pattern
Adhesion Development	Instant sealing properties, no drying or curing period
Application Temperature	Do not apply when surface or ambient temperatures are below 5C or above 30C
Roll Size	10m x 1m roll packed in cardboard cartons
Tiling Over	Polymer modified cement based adhesives only
Shelf Life	Best used within 12 months of purchase
Storage	Room temperature in dry internal conditions, stored upright vertically
Hazard Classification	Hazardous, NON-Dangerous Goods (SDS); Eye Irritation Category 2A, Skin Sensitisation Category 1
Composition	Ingredients determined to be non-hazardous, greater than 90% (SDS)
Specific Gravity	1.4 - 1.7 (SDS)
Solubility	Immiscible with water (SDS)

Frequently asked questions

View all FAQs

How do I install BRW PFN?

Application
Prime non-porous substrates with Xpress SP if needed, peel back the release liner and roll the sheet firmly onto the substrate. Use a hand roller to remove air and ensure full adhesion. Overlap joins by 50mm.
What substrates does it stick to?

Compatibility
Concrete, screed, fibre cement sheet, timber, metals, glazed surfaces, marble, granite, ceramics, plastics, PVC and existing epoxy coatings. Prime smooth/non-porous substrates with Xpress SP.
Is it certified for internal and external wet areas?

Performance
Yes – compliant to AS 4858 (internal wet areas) and AS 4654.1 (external above-ground waterproofing).
How soon can I tile over it?

Cure & Dry Time
BRW PFN is instantly waterproof once adhered – cement-based tile adhesives can be applied directly to the sheet face.
How much area does one roll cover?

Coverage & Coats
Each roll is 1m × 10m = 10 m². Allow extra for 50mm overlaps at joins.
Are there fumes or solvents?

Safety
No – it is cold-applied, solvent free and non-toxic, with no torching or heat welding required.
