What do I use the BRW PF Square for?

Sealing around floor wastes, puddle flanges, pipe penetrations, joint intersections and patching pinholes – anywhere a pre-cut sealing patch is faster than tape.

Cut the centre to suit the penetration, peel the liner and press firmly over the flange or detail. Smooth with a hand roller and overcoat with Gripset 38FC or other membrane.

Can it be used outdoors?

Yes – suitable for guttering, roofing and external flashing details, including over Colorbond, zincalume and galvanised metal.

What size is each square?

Each square is 250mm × 250mm – sized to fully cover standard floor wastes and most domestic penetrations.

How soon can I overcoat?

It is instantly sealed once pressed down – overcoat with Gripset membrane immediately after detailing.

How should the squares be stored?

Store flat in a cool, dry place away from direct sunlight. Keep release liner attached until installation.

GRIPSET BRWPF square self-adhesive butyl rubber sealing patch designed to create a waterproof seal around floor wastes, pipe penetrations, and drainage outlets before applying waterproofing membranes.

1 review

15+ bought this month

Gripset BRW PF Square Multipurpose Self-Adhesive Sealing Square

Name: Gripset BRW PF Square Multipurpose Self-Adhesive Sealing Square
Brand: Gripset
SKU: GGRG192
Price: 9.70 AUD
Availability: InStock

$9.70

or 4 interest-free payments with

Peel-and-stick butyl square for flanges, penetrations and joints. Instant seal, no priming or drying time.

Gripset BRW PF Square is a 250mm x 250mm x 0.8mm self-adhesive butyl sealing square for sealing internal and external joint intersections and penetrations. Peel it, stick it, and finish over it straight away, no drying or curing wait.

Where to use it

Sealing puddle flanges and penetrations. Bridge the flange edge and substrate, then cut an aperture in the centre to reveal the waste
Sealing joint intersections
Detailing over plumbing pipes, PVC and flashings
Reinforcement bond breaker
Patching pin holes and pitted areas on metal surfaces, guttering and roofing

Why waterproofers buy it

Instant sealing properties, no drying required
Peel and stick application, primer-less on dust free and stable surfaces
Sticks to primed or dense concrete, most metals, timber, compressed fibre cement sheeting, plasterboard, masonry, glazed surfaces, marble, granite, ceramics, plastics and polycarbonate
0.8mm butyl rubber backing, white face
Finished over with Gripset adhesives, membranes, coatings, mortars and screeds
Best used within 12 months of purchase

Not for

Exposed flashing or exposed joint seals in external applications, must be finished over with a surface covering. Not to be used as a trafficable surface. Not to be used over expansion joints. Cannot be applied over damp surfaces, seal with Gripset E60 vapour barrier primer first. Not compatible with solvent based materials applied directly over. Do not apply when surface temperature is below 5°C or above 30°C.

Instant seal with no drying or curing down time

Bridges the edge of a leak control flange and the substrate, then cut out to reveal the waste

Primer-less peel and stick on dust free and stable surfaces

Quantity: 1

7-Day Money BackGuarantee

Fast DispatchNext Business Day

Expert Advice(02) 8021 3517

Secure CheckoutSSL Encrypted

Get it — —

Pickup available at The Waterproofing Shop

Usually ready in 24 hours

Gripset BRW PF Square Multipurpose Self-Adhesive Sealing Square

The Waterproofing Shop

Pickup available, usually ready in 24 hours

22/872 Canterbury Road
Roselands NSW 2196
Australia

+61280213517

Product Details

Outstanding adhesion properties of the butyl rubber backing, the Elastoproof Butyl Square is ideal for sealing internal and external joint intersections and penetrations that require protection against moisture ingress, vibration and flexing.

Peel and stick application

Primer-less application (on dust free and stable surfaces)
Excellent adhesive properties over a variety of surfaces
Easy workability and deformability over substrates

Uses

Sealing puddle flanges and penetrations
Sealing joint intersections
Detailing over plumbing pipes, pvc, flashings etc.
Guttering & roofing
Reinforcement bond breaker
Patching pin holes and pitted areas on metal surfaces
General maintenance on surfaces to be covered over with surface finishes

Substrates

Primed or dense concrete
Galvanised iron, zincalume, copper, aluminium, colorbond and most metals
Timber
Structural sheeting
Glazed surfaces
Gypsum boards and brickwork
Marble, granite and ceramics
Plastics and polycarbonate

How to Use

Peel the release paper from the butyl side, position with the fabric face upwards and press into place with a spatula, sponge or clothConfirm all surfaces are clean, sound, smooth, dry and free of residual moisture, loose material, dirt, dust, oil, grease, wax residues, laitance, curing compounds, release agents, existing coatings, moss, algae and sharp protruding objects
Mechanically remove structurally unsound layers and surface contaminants by grinding, abrasive blasting or equivalent methods
Fill and level surface defects including voids, holes, pitted sections, heavy undulations and non-structural cracks
Confirm building surfaces are fit for purpose and installed to the manufacturer recommendations and the relevant building standards in force
Allow concrete to cure at least 28 days and cement render or sand cement screeds at least 7 days
Leave non porous and dense surfaces unprimed
Prime or seal highly porous surfaces or surfaces containing surface dust or residue with Gripset GP, E60 or Xpress H20 Primer Plus
Use Gripset E60 on surfaces containing residual moisture or subject to rising damp
Remove the release paper from the butyl rubber side and position the square with the fabric face exposed upwards
Over leak control flanges, position the square to bridge the edge of the flange and the substrate
Press into place with a spatula, sponge or cloth, pushing out air pockets and creases
Using a sharp knife, cut an aperture in the centre of the square to reveal the waste
Apply finishes immediately after the square is in place
Finish over with Gripset adhesives, membranes, coatings, mortars and screeds

Technical Specifications

Product Type: Multi-purpose self-adhesive butyl sealing square for detailing joint intersections and penetrations
Colour: White face; butyl backing grey
Size: 250mm x 250mm squares x 0.8mm thick
Thickness: 0.8mm
Solids: 100%
Specific Weight: 1.45g/cm3
Tensile Strength (EN 12311-1): Greater than 100N longitudinal and transverse directions
Elongation at Break (EN 12311-1): 70% longitudinal and transverse directions
Peel Adhesion (ASTM D1000): Greater than 80N
Loop Tack Test (ASTM D6195): Greater than 70N
Vertical Flow (ISO 7390): Less than 10mm
Cement Adhesion Strength (EN 12004 - EN1348): 1.0N/mm2 with Gripset C-Bond Adhesive
Application Temperature: 0C to 45C
Application Limit: Do not apply when surface temperature is below 5C or above 30C
Service Temperature: -40C to 100C
Adhesion Development: Instant seal, no drying required
Shelf Life: Best used within 12 months of purchase
Hazard Classification: NON-Hazardous, NON-Dangerous Goods (SDS)
TDS Revision: Issue date 01/10/2024

Product Files

Gripset BRW PF Square Multipurpose Self-Adhesive Sealing Square

$9.70

Frequently bought together

This item

Gripset BRW PF Square Multipurpose Self-Adhesive Sealing Square $9.70
Add

Gripset Elastoproof Internal Corner $8.25

Technical overview

Gripset BRW PF Square is a 250mm x 250mm x 0.8mm self-adhesive butyl sealing square used to seal internal and external joint intersections and penetrations before a waterproofing membrane or surface finish is applied. The butyl rubber backing bonds to primed or dense concrete, most metals, timber, compressed fibre cement sheeting, plasterboard, masonry, glazed surfaces, marble, granite, ceramics, plastics and polycarbonate, and gives an instant seal with no drying or curing time. Over leak control flanges the square is positioned to bridge the edge of the flange and substrate and the centre is cut out to reveal the waste. The 01/10/2024 TDS publishes EN, ISO and ASTM test values but cites no test report number and no accredited certificate.

View full technical data sheet

Key applications

Sealing puddle flanges and penetrations
Sealing joint intersections
Detailing over plumbing pipes, pvc, flashings etc.
Reinforcement bond breaker
Patching pin holes and pitted areas on metal surfaces, guttering and roofing
General maintenance on surfaces to be covered over with surface finishes

Surface suitability

Primed or dense concrete (cured at least 28 days)
Cement render and sand cement screeds (cured at least 7 days)
Galvanised iron, zincalume, copper, aluminium, Colorbond and most metals (free of oil, grease and wax residues)
Timber
Compressed fibre cement sheeting
Plasterboard
Masonry
Glazed surfaces
Marble, granite and ceramics
Plastics and polycarbonate
Highly porous surfaces or surfaces containing dust or residue (primed with Gripset GP, E60 or Xpress H20 Primer Plus)
Surfaces containing residual moisture or subject to rising damp (sealed with Gripset E60)

Not to be used as an exposed flashing or exposed joint seal in external applications and must be finished over with a surface covering. Not to be used as a trafficable surface. Not to be used over expansion joints. Cannot be applied over damp surfaces; damp must be sealed with Gripset E60 vapour barrier primer before applying the squares. Not compatible with solvent based materials applied directly over. Do not apply when surface temperature is below 5C or above 30C.

Calculate your coverage

Enter area to cover (m²) m²

You will need:

Gripset BRW PF Square Multipurpose Self-Adhesive Sealing Square

1

0 Kits

Total coverage: 0 m²

This is an estimate only. Add 10% for wastage.

Technical Specifications

Product Type	Multi-purpose self-adhesive butyl sealing square for detailing joint intersections and penetrations
Colour	White face; butyl backing grey
Size	250mm x 250mm squares x 0.8mm thick
Thickness	0.8mm
Solids	100%
Specific Weight	1.45g/cm3
Tensile Strength (EN 12311-1)	Greater than 100N longitudinal and transverse directions
Elongation at Break (EN 12311-1)	70% longitudinal and transverse directions
Peel Adhesion (ASTM D1000)	Greater than 80N
Loop Tack Test (ASTM D6195)	Greater than 70N
Vertical Flow (ISO 7390)	Less than 10mm
Cement Adhesion Strength (EN 12004 - EN1348)	1.0N/mm2 with Gripset C-Bond Adhesive
Application Temperature	0C to 45C
Application Limit	Do not apply when surface temperature is below 5C or above 30C
Service Temperature	-40C to 100C
Adhesion Development	Instant seal, no drying required
Shelf Life	Best used within 12 months of purchase
Hazard Classification	NON-Hazardous, NON-Dangerous Goods (SDS)
TDS Revision	Issue date 01/10/2024

Frequently asked questions

View all FAQs

What do I use the BRW PF Square for?

Application
Sealing around floor wastes, puddle flanges, pipe penetrations, joint intersections and patching pinholes – anywhere a pre-cut sealing patch is faster than tape.
How is it installed?

Application
Cut the centre to suit the penetration, peel the liner and press firmly over the flange or detail. Smooth with a hand roller and overcoat with Gripset 38FC or other membrane.
Can it be used outdoors?

Compatibility
Yes – suitable for guttering, roofing and external flashing details, including over Colorbond, zincalume and galvanised metal.
What size is each square?

Coverage & Coats
Each square is 250mm × 250mm – sized to fully cover standard floor wastes and most domestic penetrations.
How soon can I overcoat?

Cure & Dry Time
It is instantly sealed once pressed down – overcoat with Gripset membrane immediately after detailing.
How should the squares be stored?

Storage
Store flat in a cool, dry place away from direct sunlight. Keep release liner attached until installation.

Why trade professionals choose Gripset

Gripset supplies waterproofing membranes, primers, tapes, bond breakers and detailing components to the Australian trade, and the range is used widely on residential and commercial projects. It is built around complete systems, so the primer, the membrane and the detailing accessories are designed to work together on bathrooms, balconies, planter boxes and below-ground areas. We stock Gripset for tilers, waterproofers and builders who would rather buy the whole build-up from one place than mix components across brands.
