Pool System Build-Up
- 1 Concrete Substrate
- 2 Crack Repair (if required)
- 3 ACTFLEX FLEXPLUS
- 4 ACTFLEX HYDROPLUG
- 5 ACTFLEX AT MESH
- 6 ACTFLEX 988 CWP (2 Coats)
- 7 Tile Adhesive
- 8 Pool Finish
Woven Fabric AT-MESH 150mm x 100m
or 4 interest-free payments with
Reinforcement mesh tape for waterproofing details. 150mm wide, 100m roll. Alkali-treated fibreglass.
Woven Fabric AT-Mesh is a 150mm wide roll of alkali-treated fibreglass reinforcement mesh designed to strengthen waterproofing details and joints. Embed in membrane to reinforce corners, transitions and joints.
What it's for
- Reinforcing corners and transitions in wet area membranes
- Bridging movement and construction joints
- Strengthening membrane details at penetrations and edges
Why waterproofers buy it
- Alkali-treated fibreglass. Durable in cement environments
- Wide format reinforces large areas efficiently
- Open weave allows membrane to wet in and bond
- Long roll length covers many details
Specs
150mm wide. 100m roll. Alkali-treated fibreglass mesh.
Not for
Direct sun exposure, high-temperature applications, or structural applications requiring continuous load-bearing.
Bedded into the wet first coat and fully encapsulated, with no mesh left exposed
Required reinforcement for the three-coat 1.5 mm DFT ACTFLEX 988 CWP build
Specified for below-ground work and permanent water contact in pools and tanks
7-Day Money BackGuarantee
Fast DispatchNext Business Day
Expert Advice(02) 8021 3517
Secure CheckoutSSL Encrypted
Get it
—
—
Pickup available at The Waterproofing Shop
Usually ready in 24 hours
Woven Fabric AT-MESH 150mm x 100m
The Waterproofing Shop
22/872 Canterbury Road
Roselands NSW 2196
Australia
Product Details
How to Use
Technical Specifications
Product Files
No documentation available for this product.
Woven Fabric AT-MESH 150mm x 100m
Sale price$77.00
Frequently bought together
System Build-Up Guide
Correct application makes all the difference.
Retaining Wall System Build-Up
- 1 Concrete Substrate
- 2 Crack Repair (if required)
- 3 ACTFLEX MS PRO
- 4 ACTFLEX AT MESH
- 5 ACTFLEX 988 CWP (2 Coats)
- 6 Protection Board (Optional)
- 7 Drainage System
- 8 Backfill
Tank System Build-Up
- 1 Concrete Substrate
- 2 Crack Repair (if required)
- 3 ACTFLEX FLEXPLUS
- 4 ACTFLEX AT MESH
- 5 ACTFLEX 988 WMP (2 Coats)
- 6 Protective Coating (Optional)
- 7 Water
Technical overview
Key applications
- Floor-to-wall and wall-to-wall junctions, corners and penetrations
- Below-ground and underground waterproofing
- Permanent water contact, pools and tanks
- Water-retaining structures, three-coat system
- Negative-side waterproofing on cementitious substrates
- PVC panels, positive side, at junctions and transitions
- PVC panels, negative side, over interlocking joints
Fully encapsulate the mesh and complete the remaining coats to the specified DFT with no mesh left exposed. Press the mesh firmly to full saturation with no wrinkles or air pockets and overlap adjoining mesh by at least 50 mm. Below-ground and underground work, permanent water contact in pools and tanks, and water-retaining structures all require three coats to 1.5 mm DFT with AT-MESH. On the negative side of cementitious substrates cure the completed system before any exposure to water or hydrostatic pressure. On the negative side of PVC panels obtain project-specific approval from FORSPEC Technical Support before commencing. Check for a continuous, pinhole-free film over every cove, tape and mesh detail, and record AT-MESH placement and overlaps in the project quality records.
Technical Specifications
| Function | Reinforcement, fully encapsulated within the membrane |
| System | ACTFLEX 988 CWP cementitious waterproof membrane |
| Embedment | Into the first coat while wet, pressed firmly to full saturation with no wrinkles or air pockets |
| Minimum Overlap | 50 mm at adjoining mesh |
| Detail Coat Width | First coat applied at least 100 mm either side of the cove |
| Two-Coat System (1.2 mm DFT) | Reinforcement not required |
| Three-Coat System (1.5 mm DFT) | AT-MESH full encapsulation required |
| Below-Ground and Underground | 3 coats to 1.5 mm DFT with AT-MESH |
| Permanent Water Contact, Pools and Tanks | 3 coats to 1.5 mm DFT with AT-MESH |
| Membrane Classification | Not applicable, AT-MESH is a reinforcement component and not a membrane |
| Accredited Test Data | None held for the mesh, no Forspec Technical Data Sheet is published for AT-MESH |
Real Projects. Real Results.
-
Before
After
Pool Renovation
Gold Coast, QLD
-
Before
After
Below Ground Retaining Wall
Sydney, NSW
-
Before
After
Concrete Water Tank
Perth, WA
-
Before
After
Commercial Podium
Melbourne, VIC
-
Before After
Swimming Pool Construction
Brisbane, QLD
Watch the install
Step-by-step from prep to top coat. Filmed on the tools, not in a studio.
The Waterproofing Shop?
We supply premium waterproofing products backed by expert advice, fast service and real-world experience.
100% AustralianOwned & Operated
30+ Years in theWaterproofing Industry
Thousands of Productsin Stock
Fast ShippingAustralia Wide
Expert TechnicalSupport
Frequently asked questions
-
What is AT-MESH 150mm used for?
CompatibilityAT-MESH (150mm x 100m) is a woven polyester/polypropylene scrim used as reinforcement fabric for waterproofing details - embedded into liquid membranes over joints, cracks, and at junctions. The narrow 150mm format suits linear detail runs.
-
How does it differ from MESHTAPE?
PerformanceAT-MESH is a woven scrim with no fixed core - it provides pure reinforcement without joint movement capacity. MESHTAPE adds a thicker reinforcement bonded into a specific tape geometry. Use AT-MESH for general reinforcement, MESHTAPE for joints.
-
How is it embedded?
InstallationApply the first coat of liquid membrane, lay AT-MESH into the wet membrane along the run, then press flat with a roller to fully wet out the scrim. The membrane completely encapsulates the fabric. Apply the second coat over the top.
-
Which membranes work with it?
CompatibilityCompatible with the full Forspec liquid membrane range - cementitious (988, 989), acrylic, and polyurethane (929 HV/SL, 925, 906 WPU). The open scrim works with any chemistry.
-
Long roll length?
PerformanceThe 100m roll length suits commercial projects where you don't want to be running back to inventory mid-pour. Cuts cleanly with scissors or a utility knife for precise lengths.
